UL6500/RL350/LU-U500/SL550/FL-440/

F1P1702/UL5530/RL153/LU-U400/

SL450/FL-423/F1P1706/UL5510/RL150/

LU-U300/SL350/FL-420/F1P1710/

UL6300W/RL320/LU-W500/SL530/

FL-340/FWX1703/UL5330W/RL123/

LU-W400/SL430/FL-323/FWX1707/

UL5310W/RL120/LU-W300/SL330/

FL-320/FWX1711/UL6200/RL310/

LU-X500/SL510/FL-140/FNX1704/

UL5230/RL113/LU-X400/SL410/FL-123/

FNX1708/UL5210/RL110/LU-X300/

SL310/FL-120/FNX1712 Series

Laser Projector

User's Guide

Safety instructions

Read all of these instructions before you operate your projector and save for future

reference.

1. Read instructions

All the safety and operating instructions should be read before the appliance is

operated.

2. Notes and warnings

All notes and warnings in the operating instructions should be adhered to.

3. Cleaning

Unplug the projector from the wall socket before cleaning. Use a damp cloth for

cleaning the projector housing. Do not use liquid or aerosol cleaners.

4. Accessories

Do not place this product on an unstable cart, stand, or table. The product may fall,

causing serious damage to the product.

Keep the plastic packing materials (from the projector, accessories and optional

parts) out of the reach of children as these bags may result in death by suffocation.

Be particularly careful around the small children.

5. Ventilation

The projector is equipped with ventilation holes (intake) and ventilation holes

(exhaust).

Do not block or place anything near these slots, or internal heat build-up may

occur, causing picture degradation or damage to the projector.

6. Power sources

Check that the operating voltage of your unit is identical with the voltage of your

local power supply.

7. Servicing

Do not attempt to service this projector yourself. Refer all servicing to qualified

service personnel.

8. Replacement parts

When replacement parts are required, be sure that the replacement parts are

specified by the manufacture. Unauthorized substitutions may result in fire, electric

shock or other hazards.

9. Moisture Condensation

Never operate this projector immediately after moving it from a cold location to a

warm one. When the projector is exposed to such a change in temperature,

moisture may condense on the lens and the crucial internal parts. To prevent the

unit from possible damage, do not use the projector.

WARNING:

This is a Class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.

Table of Contents

Introduction ........................................................................................... 3

Projector feature .................................................................................................................................... 3

Package contents .................................................................................................................................. 4

Product overview ................................................................................................................................... 5

Getting Started ...................................................................................... 9

Connecting the Projector ....................................................................................................................... 9

Powering on/off the projector ............................................................................................................... 10

Adjusting the Projected Image ............................................................................................................. 11

User Controls ...................................................................................... 14

On-screen display menus .................................................................................................................... 14

Menu items .......................................................................................................................................... 15

Setting up the Projector Network Environment .................................................................................... 33

Controlling the Projector via LAN ......................................................................................................... 34

Controlling the Projector Using Crestron RoomView® ........................................................................ 37

Maintenance ........................................................................................ 42

Cleaning the projection window ........................................................................................................... 42

Cleaning the projector housing ............................................................................................................ 42

Specifications ....................................................................................................................................... 43

Dimensions .......................................................................................................................................... 45

Ceiling mount installation ..................................................................................................................... 45

Appendices.......................................................................................... 46

LED indicator messages ...................................................................................................................... 46

Compatibility Chart ............................................................................................................................... 48

Troubleshooting ................................................................................................................................... 49

RS-232C Specifications and Commands............................................................................................. 52
