Strona 1/64

PRIME /

TUF GAMING

Intel

500

Series

BIOS Manual

Motherboard

PRIME / TUF GAMING Intel

500 Series BIOS Manual

E17783

First Edition

January 2021

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

PRIME / TUF GAMING Intel

500 Series BIOS Manual

Contents

1 Knowing BIOS ............................................................................................... 4

2 BIOS Setup program ..................................................................................... 5

2.1 EZ Mode......................................................................................... 6

2.2 Advanced Mode ............................................................................. 7

3 Q-Fan Control .............................................................................................. 10

4 My Favorites menu ...................................................................................... 11

5 Main menu ................................................................................................... 12

6 Ai Tweaker menu ......................................................................................... 14

7 Advanced menu .......................................................................................... 28

7.1 Platform Misc Conguration ......................................................... 28

7.2 CPU Conguration ....................................................................... 30

7.3 System Agent (SA) Conguration ................................................ 32

7.4 PCH Conguration ....................................................................... 33

7.5 PCH Storage Conguration.......................................................... 33

7.6 PCH-FW Conguration ................................................................ 34

7.7 Thunderbolt(TM) Conguration .................................................... 35

7.8 PCI Subsystem Settings .............................................................. 37

7.9 USB Conguration ....................................................................... 38

7.10 Network Stack Conguration........................................................ 39

7.11 NVMe Conguration ..................................................................... 39

7.12 Onboard Devices Conguration ................................................... 40

7.13 APM Conguration ....................................................................... 42

7.14 HDD/SSD SMART Information .................................................... 43

8 Monitor menu .............................................................................................. 44

8.1 Temperature Monitor.................................................................... 44

8.2 Fan Speed Monitor....................................................................... 45

8.3 Voltage Monitor ............................................................................ 45

8.4 Q-Fan Conguration..................................................................... 46

9 Boot menu ................................................................................................... 51

9.1 CSM (Compatibility Support Module) ........................................... 51

9.2 Secure Boot ................................................................................. 52

9.3 Boot Conguration ....................................................................... 55

10 Tool menu .................................................................................................... 58

11 Exit menu ..................................................................................................... 61

12 Updating BIOS ............................................................................................. 62

12.1 EZ Update .................................................................................... 62

12.2 ASUS EZ Flash 3 ......................................................................... 63

12.3 ASUS CrashFree BIOS 3 ............................................................. 64

Specyfikacje produktu

Marka:	Asus
Kategoria:	płyta główna
Model:	PRIME H570-PLUS
Wysokość produktu:	53 mm
Szerokość produktu:	305 mm
Głębokość produktu:	234 mm
Waga produktu:	707 g
Obsługiwane systemy operacyjne Windows:	Windows 10
Przeznaczenie:	PC
Wi-Fi:	Nie
Kod zharmonizowanego systemu (HS):	84733020
Kanały wyjścia audio:	7.1 kan.
Liczba portów USB 2.0:	4
Przewodowa sieć LAN:	Tak
Obsługiwane rodzaje dysków:	HDD & SSD
Producent procesora:	Intel
Obsługiwane rodzaje pamięci:	DDR4-SDRAM
Liczba gniazd pamięci:	4
Bez kody korekcyjnego:	Tak
Obsługiwane prędkości zegara pamięci:	2133,2400,2666,2800,2933,3200,3333,3466,3600,3733,4000,4266,4400,4600 MHz
Maksymalna pojemność pamięci:	128 GB
Gniazdo procesora:	LGA 1200 (Socket H5)
Procesor:	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i7 Extreme Edition, Intel Core i9, Intel Pentium G
Rodzina płyt z chipsetami:	Intel
Rodzaj płyty:	ATX
Układ płyty głównej:	Intel H570
Typ BIOS:	UEFI AMI
Gniazdo zasilania ATX (24-pin):	Tak
Ilość złączy SATA III:	6
Ilość gniazd USB 2.0:	2
Łącza USB 3.2 Gen 1 (3.1 Gen 1):	2
Gniazdo wentylatora procesora:	Tak
Ilość gniazd w podstawie wentylatora:	2
Złącze audio na przednim panelu:	Tak
Liczba portów PS/2:	1
Ilość portów USB 3.2 Gen 2 (3.1 Gen 2) Typu-A:	2
Ilość portów USB 3.2 Gen 2 (3.1 Gen 2) Typu-C:	1
Ilość portów HDMI:	1
Pamięć niebuforowana:	Tak
Wspierane interfejsy dysków twardych:	M.2, SATA III
Obsługa przetwarzania równoległego:	Nieobsługiwany
Maks. rozdzielczość:	4096 x 2304 px
Ilość DisplayPort:	1
Kontroler LAN:	Intel® I219-V
Gniazdo S/PDIF:	Tak
Rozmiar pamięci BIOS:	194 Mbit
