Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53330023-01 Printed in U.S.A. Form 33CS-23SO Pg 1 8-11 Replaces: New
Owner’s Manual
Part Number 33CSCNACHP-01
SAFETY CONSIDERATIONS
Read and follow manufacturer instructions carefully. Fol-
low all local electrical codes during installation. All wiring
must conform to local and national electrical codes. Improper
wiring or installation may damage thermostat.
Recognize safety information. This is the safety alert sym-
bol . When the safety alert symbol is present on equipment
or in the instruction manual, be alert to the potential for person-
al injury.
Understand the signal words DANGER, WARNING, and
CAU
TION. These words are used with the safety alert symbol.
DANGER identifies the most serious hazards which will result
in severe personal injury or death. WARNING signifies a haz-
ard which could result in personal injury or death. CAUTION
is used to
identify unsafe practices which would result in minor
personal injury or property damage.
GENERAL
Carrier's Comfort Pro non-programmable thermostats are
wall-mounted, low-voltage thermostats which maintain space
temperature by controlling the operation of a heating and/or air
conditioning system. This thermostat can be used with a heat
pump, air conditioner or water source heat pump operation. A
variety of features are provided including battery operation,
separate heating and cooling set points, auto changeover, key-
pad lockout, and backlighting.
OPERATION
Thermostat Button Identification —
The follow-
ing buttons are located on the thermostat display. See Fig. 1 for
button locations.
• FAN (1) — Selects whether the
fan operates continu-
ously (on) or only when needed for heating or cooling
(au
to)
• MODE (2) — Selects whether thermostat is set for heat-
ing, cooling, emergency heat, auto (heat and cool as
needed), or
off
• UP (3) — Increases the temperature or adjusts
the screen
selection up when setting advanced features
• DOWN (4) — Decreases the temperature
or adjusts the
screen selection down when setting advanced features
Thermostat On-Screen Indicators — The follow-
ing on-screen indicators can be displayed on the thermostat dis-
play. See Fig. 2 for location of indicators.
• Fan mode - on or auto (1)
• Current temperature (2)
• Mode (3)
• Fahrenheit or Celsius units (4)
• Keypad is locked (no padlock means unlocked) (5)
• Battery strength indicator (6)
• Auxiliary heat (7)
• Current set point (8)
• Second stage is active (cooling or heating if available)
(9
)
1
2
4
3
mode
fan
Em
heat
cool
auto
off
auto
fan
on
aux heat
on
2
°
F
°
C
set at
actual temp
Fig. 1 — Thermostat Button Identification
a33-9223
Em
heat
cool
auto
off
auto
fan
on
aux heat
on
2
°
F
°
C
set at
actual temp
3
2
1
4
5
6
7
8
9
Fig. 2 — Thermostat On-Screen Indicators
a33-9222
Comfort™ Pro
Non-Programmable
Commercial Thermostat
