Strona 1/7
CradlePoint_MBR90-xxx
WINDOWS 7
1) Click the NETWORK CONNECTION icon
in the lower right hand corner taskbar.
You’ll see a list of available wireless networks
2) Click CradlePoint_MBR90-xxx
3) Enter Default Password
4) Click CONNECT
MBR90
Wireless N Home Ro erut
Q TAR G DEUICK S T UI
1 )
What’s In The Box
S TINET G UP THE ROUTER CONNECTING YOUR COMPUTER
WINDOWS XP
WINDOWS VISTAMAC OSX
1) Click START
2) Hover over CONNECT TO
3) Click WIRELESS NETWORK CONNECTION
You’ll see a list of available wireless networks
4) Click CradlePoint_MBR90-xxx
5) Enter Default Password
6) Click CONNECT
CradlePoint_MBR90-xxx
1) Click START
2) Hover over CONNECT TO
3) Click WIRELESS NETWORK CONNECTION
You’ll see a list of available wireless networks
4) Click CradlePoint_MBR90-xxx
5) Enter Default Password
6) Click CONNECT
1) Open your wireless connection list
by clicking the AIRPORT wireless
icon on your menu bar
You’ll see a list of available wireless
networks
2) Click on the CradlePoint_MBR90-xxx
3) Enter Default Password
12v Power Supply Ethernet Cable
( Color May Vary )
Quick Start Guide
Plug the power supply into
an electrical outlet.
Connect the power supply to the
MBR90 and turn on “ ”.
Connect a modem: Cable, DSL,
Satellite, T1, T3, USB Wireless
Broadband Data Modem with
Active Subscription, or a supported
Smart Phone with Active Data +
Tethering Plan.
Ensure the WiFi switch is on “ ”|
POWER
CABLE/DSL
MODEM
( WAN )
CONNECT
COMPUTERS
or PRINTERS
( )LAN
WiFi
ON/OFF
RESET
Using Cable, DSL, or Satellite?
Connect the provided
Ethernet cable from your
Modem into the blue WAN port.
2 )
3 )
4 )
FINDING
YOUR
PASSWORD
ET HERNET CONNECT ION
( PORT -41 )
IN T ER NET
CO NN ECT ION
Wi Fi
BROADCAST
3G/4 G
MODEM
POWER STAT US 2 3 4
Mounting Hardware
www.cradlepoint.com/mbr90
to receive support, you must register your product:
CradlePoint_MBR90-xxx
CradlePoint_MBR90-xxx
Made in Taiwan
Part number: MBR90
H/W ver.: V 1.0
F/W ver.: V 1.7.3
www.cradlepoint.com
RoHS
R06
12V 1A
FCC ID: SI5WRT383UV2
IC: 6921A-MBR900
WLAN MAC Address : 0030440cb825
Serial No.: MM100055505005
SSID:
CradlePoint_MBR90-825
MFG DATE: 02-SEP-10
WPS PIN: 25601299
Model: MBR9 00
Default Password: 440cb825
www.cradlepoint.com/mbr90
For additional information, visit:
170532-0 0 1
© 2010 CradlePoint, Inc. All rights reserved. CradlePoint is not responsible for omissions or errors in typography or photography. CradlePoint, WiPipe™,
and the WiPipe logo are trademarks of CradlePoint, Inc. in the US and other countries. Other trademarks are property of their respective owners.
NOTE: If you are asked for an “8-digit PIN”, see note on page 3.
CradlePoint_MBR
CradlePoint_M
After you connect your
modem to the router, you’re
now ready to connect to the
CradlePoint MBR90 WiFi.
802.11n antennas provide up
to 750 feet of range from the
CradlePoint router to your
connected computers or
WiFi-enabled devices.
Find your operating system
and follow the connection
steps.
Find your default password
on the bottom of your router.
NOTE: If you are asked for an
“8-digit PIN”, click CONNECT
USING A SECURITY KEY and
enter your eight character
default password.
ON/OFF
Your unique default password
is shown on the product label
on the bottom of your router.
It is the last eight characters
of your MAC Address.
You will be asked for this
password when you connect a
new device to the WiFi network
or log into the administration
pages.
The default password provides
WiFi security out-of-the-box.
3G/4 G
MODEM SLOT
(USB)
WPS
SE CU RIT Y
find this label on the bottom of your router
MODEM
SIGNAL ST RE NGT H
|
