Strona 1/4
Subwoofer Manual
Features
Models: Ti310d2, Ti310d4, Ti312d2, Ti312d4
• 40mm of Peak to Peak Excursion
• 2.5” Ultra High Temp Copper Wound Voice Coil
• Radial Backplate Venting System
• Easy Connect Single Location Speaker Terminal
• Long Throw Dual Spider Suspension
• High Excursion CAE/CAD Motor Design
• Woven Tinsel Leads
• Black Anodized Aluminum Former
• One Piece Injection Polypropylene Dustcap
• High Roll Butyl Rubber Double Stitched Surround
• Optimized for Sealed or Vented Enclosures
• Rigid Powder Coated Anti-Resonant Castbasket
• Quick Disconnect Series/Parallel Wires Included
www.phoenixgold.com
Subwoofer Owner’s Manual
Building an EncLOSURE
SEALED Enclosure Recommendations
Phoenix Gold subwoofers are overbuilt in virtually every way conceivable. It is important that the subwoofer’s enclosure
is built to these same exacting standards. The enclosure must be constructed of at least .75 inch MDF for 10 and 12 inch
subwoofers or .625 MDF for 8 inch subwoofers. Screws or air staples are excellent construction fasteners when used with
a strong bonding “yellow” wood working glue that can ll joint gaps. Be sure that the enclosure’s panels are airtight at all
joining seams. Lining the walls with a polyester matting 1 to 3 inches thick is sufcient.
Your PG dealer has extensive knowledge, tools and the experience needed for the design and construction necessary for
your subwoofer application. We also recommend you consult with your dealer for specic technical assistance related to
your installation.
The charts provided should be used as a reference when building an enclosure for your subwoofer. The charts contain
several enclosure types. The Sound Quality enclosure provides deeper, tighter, and more musical output to truly reproduce
the original source material. The SPL enclosure ts the “basshead’s” need for maximum output while sacricing some sound
quality. The normal enclosure is a balance between SPL and SQ.
SEALED
VOLUME(cu.ft.)
Ti310d2
Ti310d4
Ti312d2
Ti312d4
SPL 0.4 0.75
Normal 0.6 1.1
SQ 0.8 1.5
SPL = More overall output and compact enclosure size, but sacrices some low bass and smooth overall output
Normal = Excellent blend of low bass, accurate and strong overall outputRecommended for most listeners.
SQ = Smooth and exceptional low bass output, but larger enclosure size and sacrices some overall output
Additional Notes:
• For vented enclosures a subsonic lter set at 30Hz to 40Hz is highly recommended.
• Sealed enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer.
• Vented enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer. But DO NOT include
displacement of the vent.
• In many cases, a 4 inch round vent/port can be used instead of a rectangle/slot vent. This can reduce the vent
length and simplify the enclosure construction. However, in some rare cases at high power a small amount of
port noise maybe audible. The provided slot/rectangle ports will provide maximum performance and the most
predictable results. Contact technical support for additional enclosure options.
www.phoenixgold.com
VENTED - SQ Ti310d2
Ti310d4
Ti312d2
Ti312d4
Volume(cu.ft.) 2.0 2.0
Vent Opening(in.) 2 x 10 2 x 12
Vent Length(in.) 24 29
Tuning Freq 32Hz 32Hz
VENTED - Normal Ti310d2
Ti310d4
Ti312d2
Ti312d4
Volume(cu.ft.) 1.5 1.75
Vent Opening(in.) 2 x 10 2 x 12
Vent Length (in.) 25.5 28
Tuning Freq 36Hz 35Hz
VENTED - SPL Ti310d2
Ti310d4
Ti312d2
Ti312d4
Volume(cu.ft.) 1.25 1.75
Vent Opening(in.) 2 x 10 2 x 12
Vent Length(in.) 24.5 23.5
Tuning Freq 40Hz 38Hz
Subwoofer Owner’s Manual
Vented Enclosure Recommendations
Power HandLing Recommendations
• 400w to 600w RMS is the optimal power range for any Ti3 subwoofer. In a sealed or vented enclosure, the woofer
will play to its full potential with very high reliability.
• Powering a Ti3 woofer with more than 600w RMS will create excess heat in the motor and voice coil with minimal
additional output.
• Contrary to popular car audio myths, subwoofers do not need as much power as you think. A well engineered
subwoofer such as the Ti3, that has the proper balance of efciency, compliance and excursion will reach
extremely loud levels with much less power than most users would expect. Practice safe sound.
100w 400w 600w1w 800w
MINIMUM POWER RANGE:
Sub will perform correctly
but not to its full potential.
OPTIMAL POWER RANGE:
Sub will perform to its full
potential with maximum reliability.
DANGEROUS POWER RANGE:
Damage will occur during any
extended period of playing time.
Optimal Power Range
