Strona 1/21
D:\_SONY TV\SY160247_KHKS EU RG\4690928121\01_4690928121_GB\010COV.fm masterpage: Cover
KD-75XE90xx / 75XE85xx / 65XE90xx / 65XE85xx / 55XE90xx / 55XE85xx / 49XE90xx / FW-75XE90xx / 75XE85xx /
65XE90xx / 65XE85xx / 55XE90xx / 49XE90xx
4-690-928-12(1)
KD-75XE90xx / 75XE85xx / 65XE90xx / 65XE85xx / 55XE90xx / 55XE85xx / 49XE90xx
FW-75XE90xx / 75XE85xx / 65XE90xx / 65XE85xx / 55XE90xx / 49XE90xx
4-690-928-12(1)
Television
Reference Guide
GB
Guide de référence
FR
Guía de referencia
ES
Referentiegids
NL
Referenzanleitung
DE
Guia de referência
PT
Guida di riferimento
IT
Referensmaterial
SE
Referencevejledning
DK
Viiteopas
FI
Referanseveiledning
NO
Przewodnik
PL
Referenční příručka
CZ
Referenčná príručka
SK
Felhasználói útmutató
HU
Ghid de referinţă
RO
Информация за продукта
BG
Οδηγός αναφοράς
GR
Başvuru Kılavuzu
TR
2
GB
D:\_SONY TV\SY160247_KHKS EU RG\4690928121\01_4690928121_GB\010COVTOC_GB.fm masterpage: Left
KD-75XE90xx / 75XE85xx / 65XE90xx / 65XE85xx / 55XE90xx / 55XE85xx / 49XE90xx / FW-75XE90xx / 75XE85xx /
65XE90xx / 65XE85xx / 55XE90xx / 49XE90xx
4-690-928-12(1)
Table of Contents
IMPORTANT NOTICE . . . . . . . . . . . . . . . . . . . . 3
Safety information . . . . . . . . . . . . . . . . . . . . . 3
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Parts and Controls . . . . . . . . . . . . . . . . . . . 8
Controls and Indicators . . . . . . . . . . . . . . . . .8
Using Remote Control . . . . . . . . . . . . . . . . 9
Remote Control Parts Description. . . . . . . . .9
Connection Diagram . . . . . . . . . . . . . . . . .11
Installing the TV to the Wall . . . . . . . . . . 13
Using the optional Wall-Mount Bracket . . . 13
KD-75/65/55XE90xx,
FW-75/65/55XE90xx, KD-75XE85xx,
FW-75XE85xx only. . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . 16
Troubles and Solutions . . . . . . . . . . . . . . . . 16
Specifications . . . . . . . . . . . . . . . . . . . . . . 17
Introduction
Thank you for choosing this Sony product.
Before operating the TV, please read this manual thoroughly and
retain it for future reference.
Note
• Before operating the TV, please read the “Safety information”
(page 3).
• Images and illustrations used in the Setup Guide and this
manual are for reference only and may differ from the actual
product.
• The “xx” that appears in the model name corresponds to a
numeric digit, related to design, colour or TV system.
Location of the Setup Guide
Setup Guide is placed on top of the cushion inside the TV carton.
Help/Help Guide
Help feature offers a lot of information about your TV. To use the
Help feature, press HELP on the remote control. You can find how
to and troubleshooting from the list or keyword search. Select
[Help Guide] on Help menu to view the manual. If you connect
your TV to the internet, the Help feature and information will be
updated.
Location of the identification label
Labels for the TV Model No., Production Date (year/month) and
Power Supply rating are located on the rear of the TV or package.
For models with supplied mains adaptor:
Labels for the mains adaptor Model No. and Serial No. are located
on the bottom of the mains adaptor.
WARNING
TO PREVENT THE
SPREAD OF FIRE, KEEP
CANDLES OR OTHER OPEN
FLAMES AWAY FROM THIS
PRODUCT AT ALL TIMES.
NOTICE FOR CUSTOMERS IN THE UNITED
KINGDOM
A moulded plug complying with BS1363 is fitted to this equipment
for your safety and convenience.
Should the fuse in the plug supplied need to be replaced with the
same rating of fuse approved by ASTA or BSI to BS 1362 (i.e.,
marked with
or ) must be used.
If the plug supplied with this equipment has a detachable fuse
cover, be sure to attach the fuse cover after you change the fuse.
Never use the plug without the fuse cover. If you should lose the
fuse cover, please contact your nearest Sony service station.
How to replace the fuse
Open the fuse compartment with a blade screwdriver, and
replace the fuse.
Please refer to the illustration that actually equipped with the
product.
FUSE
Internet Connection and Data Privacy
This product connects to the internet during initial setup as
soon as a network is connected in order to confirm internet
connection, and later to configure the Home screen. Your IP
address is used in these and all other internet connections. If
you do not want your IP address be used at all, do not set-up
the wireless internet function and do not connect an internet
cable. Please refer to the privacy information presented in the
set-up screens for further details of internet connections.
3
GB
D:\_SONY TV\SY160247_KHKS EU RG\4690928121\01_4690928121_GB\010COVTOC_GB.fm masterpage: Right
GB
KD-75XE90xx / 75XE85xx / 65XE90xx / 65XE85xx / 55XE90xx / 55XE85xx / 49XE90xx / FW-75XE90xx / 75XE85xx /
65XE90xx / 65XE85xx / 55XE90xx / 49XE90xx
4-690-928-12(1)
Notice for Radio Equipment
Hereby, Sony Corporation declares that
the radio equipment types KD-75XE9005,
KD-75XE8596, KD-65XE9005,
KD-65XE8599, KD-65XE8596, KD-65XE8588, KD-65XE8577,
KD-65XE8505, KD-55XE9005, KD-55XE8599, KD-55XE8596,
KD-55XE8588, KD-55XE8577, KD-55XE8505, KD-49XE9005,
FW-75XE9001, FW-75XE8501, FW-65XE9001, FW-65XE8501,
FW-55XE9001, FW-49XE9001 are in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC. For details, please access the following URL:
http://www.compliance.sony.de/
This radio equipment can be operated in the EU without
infringing applicable requirements on the use of radio spectrum.
Notice for customers: the following information is only applicable
to equipment sold in countries applying EU directives.
TV wireless system may be operated in following countries:
AT, BE, HR, CY, CZ, DK, EE, FI, FR, DE, GR, HU, IE, IT, LV, LT, LU, MT,
NL, PL, PT, SK, SI, ES, SE, GB, IS, LI, NO, CH, BG, RO, TR, AL, BA, MK,
MD, RS, ME, Kosovo
This equipment can be operated in other non-European
countries.
WARNING
Batteries must not be exposed to excessive heat such as
sunshine, fire or the like.
Never place a television set in an unstable location. A television
set may fall, causing serious personal injury or death. Many
injuries, particularly to children, can be avoided by taking simple
precautions such as:
Using cabinets or stands recommended by the manufacturer of
the television set.
Only using furniture that can safely support the television set.
Ensuring the television set is not overhanging the edge of the
supporting furniture.
Not placing the television set on tall furniture (for example,
cupboards or bookcases) without anchoring both the furniture
and the television set to a suitable support.
Not placing the television set on cloth or other materials that
may be located between the television set and supporting
furniture.
Educating children about the dangers of climbing on furniture
to reach the television set or its controls.
If your existing television set is being retained and relocated, the
same considerations as above should be applied.
Installation/Set-up
Install and use the TV set in accordance with the instructions
below in order to avoid any risk of fire, electric shock or damage
and/or injuries.
Installation
• The TV set should be installed near an easily accessible mains
socket.
• Place the TV on a stable, level surface to prevent it from falling
over and causing personal injury or property damage.
• Install the TV where it cannot be pulled, pushed, or knocked
over.
• Install the TV so that the TV's Table-Top Stand does not protrude
out from the TV stand (not supplied). If the Table-Top Stand
protrudes out from the TV stand, it may cause TV set to topple
over, fall down, and cause personal injury or damage to the TV.
KD-75/65/55/49XE90xx, FW-75/65/55/49XE90xx
KD-75/65/55XE85xx, FW-75/65XE85xx
• Only qualified service personnel should carry out wall-mount
installations.
• For safety reasons, it is strongly recommended that you use
Sony accessories, including:
Wall-Mount Bracket SU-WL450 (Except KD-75XE90xx,
KD-75XE85xx, FW-75XE90xx, FW-75XE85xx)
• Be sure to use the screws supplied with the Wall-Mount Bracket
when attaching the Wall-Mount Bracket to the TV set. The
supplied screws are designed as indicated by illustration when
measured from the attaching surface of the Wall-Mount Bracket.
The diameter and length of the screws differ depending on the
Wall-Mount Bracket model.
Use of screws other than those supplied may result in internal
damage to the TV set or cause it to fall, etc.
IMPORTANT NOTICE
This product has been manufactured by or on behalf of Sony
Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan.
Inquiries related to product compliance based on European
Union legislation shall be addressed to the authorized
representative, Sony Belgium, bijkantoor van Sony Europe
Limited, Da Vincilaan 7-D1, 1935 Zaventem, Belgium. For any
service or guarantee matters, please refer to the addresses
provided in the separate service or guarantee documents.
Safety information
Screw (M6)
Wall-Mount Bracket
8 mm - 12 mm
TV’s rear cover
