5-048-168- (1)11
Optional Camera and Microphone Unit (not supplied) Cable Management /
選購的攝影機與麥克風組件（無附帶）線材管理
EN
Note
•Instructions about “Installing the TV to the Wall”
are included within this TV’s instruction manual.
•Read the supplied safety documentation for
additional safety information.
Location of the identification label
Labels for the TV Model No. and Power Supply
rating are located on the rear of the TV.
This television is designed for use in Hong Kong
and ensured the usage in Hong Kong only.
Installing the TV to the Wall
Using the optional Wall-Mount Bracket (SU-WL850 or
SU-WL450)* (not supplied)
To Customers:
For product protection and safety reasons, Sony
strongly recommends that installation of your TV
be performed by Sony dealers or licensed
contractors. Do not attempt to install it yourself.
To Sony Dealers and Contractors:
Provide full attention to safety during the
installation, periodic maintenance and
examination of this product.
Wall-Mount Bracket Installation Information
For instructions on Wall-Mount Bracket installation,
see the Installation Information (Wall-Mount
Bracket) on the product page for your TV model.
https://www.sony-asia.com/support
•Follow the instruction guide provided with the
Wall-Mount Bracket for your model. Sufficient
expertise is required in installing this TV,
especially to determine the strength of the wall
for withstanding the TV’s weight.
•Sony is not liable for any damage or injury caused
by mishandling or improper installation.
•Only qualified service personnel should carry out
wall-mount installations.
•For safety reasons, it is strongly recommended
that you use Sony accessories, including:
— Wall-Mount Bracket SU-WL850
— Wall-Mount Bracket SU-WL450
•Be sure to use the screws supplied with the
Wall-Mount Bracket when attaching the Wall-
Mount Bracket to the TV set. The supplied screws
are designed as indicated by illustration when
measured from the attaching surface of the Wall-
Mount Bracket.
The diameter and length of the screws differ
depending on the Wall-Mount Bracket model.
Use of screws other than those supplied may
result in internal damage to the TV set or cause
it to fall, etc.
•Be sure to store the unused screws and Table-Top
Stand in a safe place until you are ready to attach
the Table-Top Stand. Keep the screws away from
small children.
* Only for limited region/country/model.
Troubleshooting
General troubleshooting for issues like: black
screen, no sound, frozen picture, TV does not
respond, or network is lost, do the following steps.
1 Restart your TV by pressing the power button
on the remote control for about five seconds.
The TV will restart. If the TV does not recover, try
unplugging the AC power cord (mains lead)
then press the power button on the TV and
release it. Wait for two minutes, and plug in the
AC power cord (mains lead).
Or, press the power button on the TV for about
40seconds until the TV turns off.
2 Refer to the Help menu shown below.
3 Connect your TV to the Internet and perform a
software update. Sony recommends you to
keep your TV software updated. Software
updates provide new features and performance
improvements.
4 Visit Sony support website (information
provided at the end of the supplied safety
documentation).
When you plug in the TV, the TV may not be
able to turn on for a while even if you press
the power button on the remote control or
the TV.
It takes time to initialize the system. Wait for about
one minute, then operate it again.
The remote control does not function.
•Replace the batteries.
The parental lock password has been
forgotten.
•Enter 9999 for the PIN and enter the new PIN.
For more information, refer to
the Help Guide.
Press (Input select) on the
remote control and select [Help].
If [Help] does not exist, select
[Edit] and add [Help].
Specifications
System
Panel system
LCD (Liquid Crystal Display) Panel, LED Backlight
TV system
Analogue: I, D/K, B/G, M
Digital: DTMB
Colour system
PAL/SECAM/NTSC3.58/NTSC4.43
Channel coverage
Analogue: UHF/VHF/Cable
Digital: UHF
Sound output (W)
10 + 10
Wireless technology
Protocol IEEE 802.11a/b/g/n/ac
Bluetooth® Version 4.2
Input/Output jacks
Antenna (aerial)/cable
75 ohm external terminal for VHF/UHF
HDMI IN 1/2/3/4 (HDCP 2.3-compatible)
Video:
4096 × 2160p (50, 60 Hz)*1*2, 4096 × 2160p
(24 Hz)*1, 3840 × 2160p (50, 60 Hz)*2, 3840 × 2160p
(24, 25, 30 Hz), 1080p (24, 30, 50, 60 Hz), 1080i (50,
60 Hz), 720p (24, 30, 50, 60 Hz), 576p, 480p,
PC Formats*3
Audio:
In eARC (Enhanced Audio Return Channel) mode
Refer to the online Help Guide for details.
Except eARC mode
5.1 channel linear PCM: 32/44.1/48/88.2/96/
176.4/192 kHz 16/20/24 bits, Dolby Audio, Dolby
Atmos, DTS
eARC/ARC (Enhanced Audio Return Channel/
Audio Return Channel) (HDMI IN 3 only)*4
In eARC mode
Refer to the online Help Guide for details.
In ARC mode
Two channel linear PCM: 48 kHz 16 bits, Dolby
Audio, Dolby Atmos, DTS
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear PCM:
48 kHz 16 bits, Dolby Audio, DTS)
1, 2
USB port 1 supports High Speed USB (USB 2.0)
USB port 2 supports Super Speed USB (USB 3.2
Gen 1)
LAN
10BASE-T/100BASE-TX connector (Depending on
the operating environment of the network,
connection speed may differ. The communication
rate and quality are not guaranteed.)
Power and others
Power requirements
220 V - 240 V AC, 50 Hz
Screen size (measured diagonally) (Approx.)
(inches/cm)
KD-75X80L: 75 / 189.3
KD-65X80L: 65 / 163.9
KD-55X80L: 55 / 138.8
KD-50X80L: 50 / 125.7
KD-43X80L: 43 / 108.0
Power consumption
Indicated on the rear of the TV
Standby power consumption*5*6 (W)
0.5
Display resolution (horizontal × vertical) (pixels)
3840 × 2160
Output rating
500 mA (for USB 1), 900 mA (for USB 2)
Others
Optional accessories
Wall-Mount Bracket: SU-WL850 (except
KD-50X80L / 43X80L), SU-WL450
Camera and Microphone Unit: CMU-BC1
Operating temperature
0 ºC – 40 ºC
Operating humidity
10% – 80% RH (non-condensing)
*1 When 4096 × 2160p is input and [Wide mode]
is set to [Normal], the resolution is displayed
as 3840 × 2160p. To display 4096 × 2160p, set
[Wide mode] setting to [Full 1] or [Full 2].
*2 Refer to the on screen menu to set [HDMI signal
format].
*3 Refer to the online Help Guide for details.
*4 Connect your audio system to the HDMI IN 3 to
route TV audio to your audio system.
*5 Specified standby power is reached after the TV
finishes necessary internal processes.
*6 Standby power consumption will increase when
your TV is connected to the network.
Note
•Optional accessories availability depends on
countries/region/TV model/stock.
•Design and specifications are subject to change
without notice.
•Subscriptions for services and applications may
be required and additional terms, conditions
and/or charges may apply when using Google
Assistant.
•Power consumption will increase when the built-
in MIC is enabled as it is always listening.
•Visit Sony website for more information on
product specifications.
Trademark Information
•Dolby, Dolby Vision, Dolby Atmos, Dolby Audio,
and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
Manufactured under license from Dolby
Laboratories. Confidential unpublished works.
Copyright © 1992-2022 Dolby Laboratories. All
rights reserved.
•Gracenote, the Gracenote logo and logotype,
“Powered by Gracenote” logo are either
registered trademarks or trademarks of
Gracenote, Inc. in the United States and/or other
countries.
•For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc. DTS,
Digital Surround, and the DTS logo are registered
trademarks or trademarks of DTS, Inc. in the
United States and other countries. © 2020 DTS,
Inc. ALL RIGHTS RESERVED.
•TUXERA is a registered trademark of Tuxera Inc. in
the US and other countries.
MIC
EN
The remote control shape, layout, availability
and function of remote control buttons may vary
depending on your region/country/TV model/
TV settings.*1
(Power)
TV: Display TV channel list or switch to input.
(Quick settings): Display Quick Settings.
(Input select): Display and select the
input source, etc.
(Control menu): Display the Control
menu.
/ / / / : On screen menu
navigation and selection.
(Back)
(Home)
(Google Assistant / Microphone): Use
Google Assistant*2*3 or voice search*3.
+ / – (Volume)
(Mute)*4
CH + / – (Channel)
(Dashboard): Display Dashboard.
(Guide): Display the digital programme
guide.
App buttons
*1 For other remote control models, refer to the
online Help Guide for details.
*2 Only for limited region/country/model/
language.
*3 Google Assistant or voice search requires an
Internet connection.
*4 Accessibility shortcut is available by pressing
and holding (Mute).
CT
遙控器外形、按鈕的佈局、可用性與功能視您的國
家／區域／電視機型號或設定而可能略有不同。*1
（電源）
TV：顯示電視機頻道清單或切換為輸入。
（快速設定）：顯示快速設定。
（輸入選擇）：顯示並選擇輸入來源等。
（控制選單）：顯示控制選單。
/ / / / ：在螢幕選單導航和選
擇上。
（返回）
（主選單）
（Google助理／麥克風）：使用Google
助理*2*3或語音搜尋*3。
+/-（音量）
（靜音)*4
CH+/-（頻道）
（資訊主頁）：顯示資訊主頁。
（指南）：顯示數位節目指南。
應用按鈕
*1有關其他遙控器型號，請參閱線上說明指南以獲
取詳情。
*2僅限用於有限區域／國家／型號／語言。
*3使用Google助理或語音搜尋需要網際網路連
線。
*4按住 （靜音）可使用輔助使用快捷鍵。
KD-75X80L / 65X80L / 55X80L / 50X80L / 43X80L
Reference Guide
參考指南
Television
https://rd1.sony.net/help/tv/kga1/h_ga/
CT
註
•有關“將電視機安裝在牆上”的指示已包含在這台
電視機的使用說明書。
•有關其他安全資訊，請閱讀隨附的安全檔案。
識別標籤的位置
電視機型號和電源等級的標籤位於電視機背面。
本電視設計在香港使用，只保證能在香港使用。
將電視機安裝在牆上
使用選購的壁掛式支架（SU-WL850或
SU-WL450)
*（非附帶）
致客戶：
出於產品保護及安全原因，Sony強烈建議由Sony經
銷商或授權的承包商安裝電視機。請勿嘗試自行安裝
電視機。
致Sony經銷商和承包商：
安裝、定期維護及檢查本產品時，請充分注意安全。
壁掛式支架安裝資訊
有關壁掛式支架安裝的說明，請參閱您的電視機型號
的產品頁上的安裝訊息（壁掛式支架）。
https://www.sony-asia.com/support
•請遵循適合您的型號的壁掛式支架隨附的使用說明
手冊。安裝本電視機須具備充足的專業知識，確定
牆壁是否能夠承受電視重量時尤為如此。
•對於因錯誤操作或安裝不當引致的任何損害，Sony
概不負責。
•僅可由合格的維修人員執行掛壁安裝。
•為了安全起見，強烈建議您使用Sony配件，
包括：
— 壁掛式支架SU-WL850
— 壁掛式支架SU-WL450
•將壁掛式支架安裝於電視機上時，務必要使用隨附
於壁掛式支架的螺絲。隨附螺絲如插圖所示設計從
壁掛式支架安裝表面量起。
螺絲的直徑和長度會因為壁掛式支架的型號而有
所不同。
使用隨附螺絲以外的螺絲可能會造成電視機內部損
壞或者掉落等等。
•務必將未使用的螺絲及桌面底座存放於安全位置，
直到您已準備好連接桌面底座。請將螺絲存放在兒
童接觸不到的位置。
*僅限用於有限區域／國家／型號。
故障排除
以下問題的一般故障排除：黑螢幕、沒有聲音、凍結
畫面、電視機沒有反應或網絡丟失，請依照以下步驟
操作。
1 按遙控器上的電源按鈕大約五秒重新啟動電視
機。電視機將重新啟動。如果電視機未恢復正
常，請嘗試拔下AC電源線，然後按電視機上的電
源按鈕再鬆開此按鈕。等候兩分鐘，隨後插入AC
電源線。
或者按電視機上的電源按鈕約四十秒，直到電視
機關閉。
2 請參閱如下所示的說明選單。
3 將電視機連接至網路，然後執行軟件更新。Sony
建議您不斷更新您的電視機軟件。軟件更新將提
供新功能和效能改善。
4 造訪Sony支援網站（提供的資訊在隨附安全文
檔末尾）。
在插入電視機時，即使按遙控器或電視機上的電
源按鈕，電視機也可能在一定時間不能開啟。
系統初始化需要一定時間。等待大約一分鐘，然後再
次操作。
遙控器無效。
•更換電池。
忘記家長鎖定的密碼。
•PIN碼輸入9999，然後輸入新的PIN碼。
© 2023 Sony Corporation
(mm/ )毫米 *1(kg/
千克)*1
KD-75X80L 962 73 32.21675
KD-65X80L 1452 836 72 21.7
KD-55X80L 1233 713 72 15.9
KD-50X80L 1119 12.4649 70
KD-43X80L 964 563 69 10.1 *1 (Approx. / 大約)
(mm/ )毫米 *1(kg/
千克)*1
KD-75X80L 1036 3991675 33.7
KD-65X80L 1452 908 336 22.8
KD-55X80L 1233 785 336 17
KD-50X80L 1119 716 284 13.1
KD-43X80L 964 284630 10.8 *1 (Approx. / 大約)
Wall-Mount Attachment
VS
/ 壁掛連接件
VS
Wall-Mount Bracket / 壁掛式支架
10 – 12 (mm)
M6
(mm) / (毫米)
Specyfikacje produktu
| Marka: | Sony |
| Kategoria: | Telewizja |
| Model: | KD-75X80L |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Sony KD-75X80L, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje Telewizja Sony
4 Kwietnia 2025
4 Kwietnia 2025
4 Kwietnia 2025
12 Marca 2025
12 Marca 2025
25 Stycznia 2025
13 Stycznia 2025
13 Stycznia 2025
22 Grudnia 2024
22 Grudnia 2024
Instrukcje Telewizja
Najnowsze instrukcje dla Telewizja
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
