Strona 1/12

B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

DESIGNED FOR USE WITH;

FEATURES

BT4003

LARGE FLOOR / TROLLEY BASE

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Floor / Trolley Base

PLEASE KEEP THIS FOR FUTURE REFERENCE

BT4005 / BT4011 / BT4015 /

BT4020 Ø60mm pole

(Sold Separately)

Installation Safety Notes.....................................................................................................................2

Parts List............................................................................................................................................4

Installation Instructions.......................................................................................................................6

Optional Accessories..............................................................................................................................9

Typical Installations...............................................................................................................................10

Product Dimensions..........................................................................................................................11

B-Tech Contact Details.....................................................................................................................12

Community Design No.

001713280-0019

● Designed for flat screens up to 50” (153cm) / 70kg (154lbs)

● Suitable for 1 or 2 column support installations

● Supplied with levelling feet

● Overall dimensions (with feet);

1046mm (41.2”) x 711mm (28”) x 60mm (2.4”)

* BTW100-4 wheels sold separately

* Support columns and screen mounting plate are sold separately

Actual screen size & weight limit
