Strona 1/12
B-TECH AUDIO VIDEO MOUNTS
www.btechavmounts.com
CONTENTS
INSTALLATION TOOLS REQUIRED
FEATURES
BT7505
UNIVERSAL FLAT SCREEN ADAPTOR PLATE
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Adaptor Pate
Crosshead
screwdriver
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Sample Installations...............................................................................................................................10
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
PLEASE KEEP THIS FOR FUTURE REFERENCE
Designed for flat screens up to 40” (101cm) / 40kg (88lbs)
Universal adaptor kit to allow fitting of Non-VESA screens to
75 x 75mm and 100 x 100mm VESA mounts
Simple installation with all mounting hardware included
Must be used with a 75 x 75mm or 100 x 100mm
VESA flat screen mount (BT7510 / BT7511 / BT7512 / BT7513
/ BT7514 / BT7515 / BT7518 / BT7519 / BT7521 / BT7522)
Wall / ceiling / stand /
bracket sold
separately
Actual screen size & weight limit
dependant on mount to which
BT7505 is attached


Specyfikacje produktu

Marka: B-tech
Kategoria: Wsparcie dla płaskich paneli
Model: BT7505
