B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

BT7582

SMALL FLAT SCREEN CEILING MOUNT

WITH TILT AND SWIVEL

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

Crosshead

screwdriver

Drill

12mm (1/2") masonry bit

or 9mm (3/8") wood bit

Pencil

Stud finder

(optional)

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Installation Instructions.......................................................................................................................6

Product Dimensions..........................................................................................................................11

B-Tech Contact Details.....................................................................................................................12

PLEASE KEEP THIS FOR FUTURE REFERENCE

15mm (9/16")

spanner or socket

● Fits 50 x 50mm, 75 x 75mm and 100 x 100mm

VESA mounting patterns

● Adjustable ceiling drop: 560mm (22”) – 800mm (31.5”)

● Upper tube diameter: 42mm (1.7”)

● Lower tube diameter: 35mm (1.4”)

● +/-50° Tilt of pole for angled ceilings
