B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

BT8223

DOUBLE ARM FLAT SCREEN MOUNT

FOR EXTRA LARGE SCREENS

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

PLEASE KEEP THIS FOR FUTURE REFERENCE

● Designed for flat screens up to 65” (165cm) / 60kg (132lbs)

● Fits screens with VESA & Non-VESA mounting patterns

up to 790mm (31.1”) x 500mm (20”)

● Easy tilt adjustment +15°

● Features three swivel points:

180° at wall, 360° at central pivot and 180° at interface

● Suitable for concrete / brick or stud walls up to 16”

● Simple ‘hook-on’ installation with all

mounting hardware included

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Installation Instructions.......................................................................................................................6

Product Dimensions..........................................................................................................................18

B-Tech Contact Details.....................................................................................................................20

12mm (15/32") masonry bit

or 8mm (5/16") wood bit

Crosshead

screwdriver

Drill

Pencil

Stud finder

(optional)

17mm (17/26")
