Technology Features
• ExtraordinAir™ Threading
• Automatic Thread Delivery™
System
• Pure Lighting with 6 LED lights
• Wide workspace of 5" to right
of needle and 3" tall
• Full-Featured Differential Feed
- 2 to 1 ratio - gathering
- 3 to 4 ratio - stretching
• Knee lift
• Variable sewing speed control
Advanced Serging Features
• Exclusive Wave Stitch and
Reverse Wave Stitch for
additional stitch options
• Serging options from 2 to 8
threads
• Chain/cover stitch functions
include single, double and
triple cover stitch
• Overlock stitch functions to
seam and encase fabric edges
• Flatlock stitch functions for
seaming or decorative effects
• Advanced cutting system
handles thick fabrics with ease
• Automatic rolled hem
stitch functions create a
professional finish
• Dial adjustable stitch width:
1.5mm - 7.5mm, up to 16mm
wide on expressive stitches
• Dial adjustable stitch length:
0.75mm - 4mm
• Dial adjustable built-in
rolled hem
• Bypass port for special thread
• Up to 1,500 stitches
per minute
• Adjustable presser foot
pressure dial
Convenience Features
• Built-in thread cutter
• Electronic foot control and
separate power cord
• Presser foot lever in front for
easy access
• Snap-on, multi-purpose
presser foot
• Built-in larger accessory storage
• Built-in ribbon/tape guides
• Easy full-color threading chart
• Color-coded single antennae
with thread guides
• Wide sewing table for chain/
cover stitching
• Needle drop tray with magnet
• Needle clamp safety plate
prevents lost needle screws
• Safety switch on front door
cover
• Power cord manager on
machine base
Other
• Household Needle System
- ELx705
- ELx705CF
• Warranty (25 yrs. limited,
10 yrs. parts, 5 yrs. electrical,
1 yr. labor)
www.babylock.com
Ovation
08/13
Optional Accessories
• Beading Foot BLE8-BF
• Belt Loop Binder 3/4” BLE8-S12
• Belt Loop Binder 1-1/2" BLE8-S11
• Blindhem Foot BLE8-BLHF
• Clear Foot BLE8-CLF
• Cording Foot BLE8-CF
• Cover Chain Foot BLE8-CCF
• Curve Foot BLE8-CVF
• Double Fold Bias Binder 28mm BLE8-S3
• Double Fold Bias Binder 36mm BLE8-S2
• Elastic Foot BLE8-EF
• Extension Table BLE8-ET
• Fabric Guide BLES8-FG
• Lace Applicator Foot BLE8-LF
• Pintuck Foot with Guide BLE8-PTF
• Plain Hemmer 1/4” BLE8-S7
• Plain Hemmer 1/2” BLE8-S6
• Quilt Guide BLES8-QG
• Ruffling Foot BLE8-RF
• Serger Trolley Bag BLOST
• Single Downturn Feller 1/4” BLE8-S10
• Single Downturn Feller 5/8” BLE8-S8
• Single Downturn Feller 1” BLE8-S9
• Single Fold Bias Binder 28mm BLE8-S4
• Single Fold Bias Binder 40mm BLE8-S5
• Trim Bin BLTBIN
• 22 Accessories/Foot Kit BLES8FTKIT
• Inspirational Guide
• Gold Standard Comprehensive Care
Program (available in the U.S.)
Fabric Support System
The Fabric Support System keeps
stitches flat and balanced, no matter
what speed, fabric or stitch you choose.
The built-in stitch fingers actually move
with the knife blade, adjusting the seam
consecutively with the cutting width.
Vertical Needle Penetration
While most machines use slanted
needles that push and damage fabric,
Baby Lock’s needles are set vertically
and sew directly up and down. This
exclusive feature protects your fabric
and prevents needle deflection.
Chain/Cover Tension Disks
Baby Lock revolutionized the cover stitch
with the Ovation — functions include
chain, cover, and triple cover stitches.
All three cover needles are controlled by
one tension dial, so you can save time
with one simple adjustment.
8/7/6 Thread Stitch Capacity
With eight threads, the Ovation gives
you 87 stitch combinations. Plus, you
can combine overlocking and cover
stitching in the same operation.
Cover Stitch Chaining Off
Baby Lock has made cover stitching
easy to start or stop by automatically
chaining off the cover stitch. What’s
more, the Ovation sews through
heavier fabrics better than most cover
stitch machines.
Thread Delivery Unit for the
Wave Stitch
For a stitch as unique as the Wave
Stitch, Baby Lock wanted to ensure
that each wave would be even with
the next. To do so, they created a
thread delivery unit to give each
one a flawless look.
LBSP-BLES8
Ovation
It’s Time for an Outstanding Performance
Specyfikacje produktu
| Marka: | Baby Lock |
| Kategoria: | maszyna do szycia |
| Model: | Ovation - BLES8 |
