en Safety

Further information and explanations are available online:

Table of contents

INFORMATION FOR USE

1 Safety...................................................................2

2 Preventing material damage ..............................4

3 Environmental protection and saving en-

ergy ......................................................................5

4 Familiarising yourself with your appliance .......6

5 Operating modes ................................................8

6 Accessories.......................................................10

7 Before using for the first time ..........................11

8 Basic operation .................................................13

9 Rapid heating ....................................................14

10 Time-setting options.........................................14

11 Steam.................................................................16

12 Dishes................................................................19

13 Favourites..........................................................20

14 Childproof lock..................................................21

15 Basic settings....................................................21

16 HomeConnect ..................................................23

17 Cleaning and servicing.....................................24

18 Cleaning aid.......................................................27

19 Descaling...........................................................27

20 Drying ................................................................28

21 Appliance door..................................................28

22 Rails ...................................................................32

23 Troubleshooting................................................33

24 Disposal.............................................................35

25 Customer Service..............................................35

26 Information regarding Free and Open

Source Software................................................36

27 Declaration of Conformity ................................36

28 How it works......................................................36

29 INSTALLATION INSTRUCTIONS ......................45

29.1 General installation instructions......................45

1 Safety

Observe the following safety instructions.

1.1 General information

¡Read this instruction manual carefully.

¡Keep the instruction manual and the

product information safe for future refer-

ence or for the next owner.

¡Do not connect the appliance if it has been

damaged in transit.

1.2 Intended use

This appliance is designed only to be built

into kitchen units. Read the special installation

instructions.

Only a licensed professional may connect ap-

pliances without plugs. Damage caused by in-

correct connection is not covered under the

warranty.

Only use this appliance:

¡To prepare meals and drinks.

¡in private households and in enclosed

spaces in a domestic environment.

¡up to an altitude of max. 2000m above

sea level.

1.3 Restriction on user group

This appliance may be used by children aged

8 or over and by people who have reduced

physical, sensory or mental abilities or inad-

equate experience and/or knowledge,

provided that they are supervised or have

been instructed on how to use the appliance

safely and have understood the resulting

dangers.

Do not let children play with the appliance.

Children must not perform cleaning or user

maintenance unless they are at least 15 years

old and are being supervised.

Safety en

Keep children under the age of 8 years away

from the appliance and power cable.

1.4 Safe use

Always place accessories in the cooking com-

partment the right way round.

→"Accessories", Page10

WARNING‒Risk of fire!

Combustible objects that are left in the cook-

ing compartment may catch fire.

▶Never store combustible objects in the

cooking compartment.

▶If smoke is emitted, the appliance must be

switched off or the plug must be pulled out

and the door must be held closed in order

to stifle any flames.

Loose food remnants, fat and meat juices

may catch fire.

▶Before using the appliance, remove the

worst of the food residues and remnants

from the cooking compartment, heating ele-

ments and accessories.

Opening the appliance door creates a

draught. Greaseproof paper may come into

contact with the heating element and catch

fire.

▶Never place greaseproof paper loosely

over accessories when preheating the ap-

pliance and while cooking.

▶Always cut greaseproof paper to size and

use a plate or baking tin to hold it down.

WARNING‒Risk of burns!

The appliance and its parts that can be

touched become hot during use.

▶Caution should be exercised here in order

to avoid touching heating elements.

▶Young children under 8 years of age must

be kept away from the appliance.

Accessories and cookware get very hot.

▶Always use oven gloves to remove ac-

cessories or cookware from the cooking

compartment.

When the cooking compartment is hot, any al-

coholic vapours inside may catch fire. The ap-

pliance door may spring open. Hot steam and

jets of flame may escape.

▶Only use small quantities of drinks with a

high alcohol content in food.

▶Do not heat spirits (≥ 15% vol.) when undi-

luted (e.g. for marinating or pouring over

food).

▶Open the appliance door carefully.

WARNING‒Risk of scalding!

The accessible parts of the appliance become

hot during operation.

▶Never touch these hot parts.

▶Keep children at a safe distance.

Hot steam may escape when you open the

appliance door. Steam may not be visible, de-

pending on the temperature.

▶Open the appliance door carefully.

▶Keep children at a safe distance.

If there is water in the cooking compartment

when it is hot, this may create hot steam.

▶Never pour water into the cooking compart-

ment when the cooking compartment is

hot.

WARNING‒Risk of injury!

Scratched glass in the appliance door may

develop into a crack.

▶Do not use any harsh or abrasive cleaners

or sharp metal scrapers to clean the glass

on the oven door, as they may scratch the

surface.

The appliance and its parts that can be

touched may have sharp edges.

▶Take care when handling and cleaning

them.

▶If possible, wear protective gloves.

The hinges on the appliance door move when

the door is opened and closed, which could

trap your fingers.

▶Keep your hands away from the hinges.

Components inside the appliance door may

have sharp edges.

▶Wear protective gloves.

WARNING‒Risk of electric shock!

Improper repairs are dangerous.

▶Repairs to the appliance should only be

carried out by trained specialist staff.

▶Only use genuine spare parts when repair-

ing the appliance.

▶If the power cord of this appliance is dam-

aged, it must be replaced by trained spe-

cialist staff.

If the insulation of the power cord is dam-

aged, this is dangerous.

▶Never let the power cord come into contact

with hot appliance parts or heat sources.

▶Never let the power cord come into contact

with sharp points or edges.

▶Never kink, crush or modify the power

cord.

Specyfikacje produktu

Marka:	Bosch
Kategoria:	piekarnik
Model:	CSG7361B1
Kolor produktu:	Czarny
Pojemność zbiornika na wodę:	1 l
Typ kontroli:	Dotyk
Wbudowany wyświetlacz:	Tak
Długość przewodu:	1.5 m
Typ wyświetlacza:	TFT
Częstotliwość wejściowa AC:	50 - 60 Hz
Napięcie wejściowe AC:	220 - 240 V
Wysokość produktu:	455 mm
Szerokość produktu:	594 mm
Głębokość produktu:	548 mm
Waga produktu:	36900 g
Szerokość przedziału instalacji:	568 mm
Głębokość przedziału instalacji:	550 mm
Minimalna wysokość przedziału instalacji:	450 mm
Maksymalna wysokość przedziału instalacji:	455 mm
Prąd:	16 A
Obciążenie:	3300 W
Klasa wydajności energetycznej:	A+
Skala efektywności energetycznej:	A +++ do D
Zawias drzwiczek:	W dół
Rozmiar piekarnika:	Średni
Pojemność wnętrza wszystkich piekarników:	47 l
Szerokość przedziału instalacyjnego (min):	560 mm
Zakres temperatury gotowania:	30 - 250 °C
