INSTALLATION INSTRUCTIONS

PAC115-116-117

Legrand AV and its affiliated corporations and subsidiaries (collectively “Legrand AV”), intend to make this manual accurate and complete. However, Legrand AV makes no claim|||

that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this

product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand AV makes no representation of warranty, expressed or|

implied, regarding the information contained herein. Legrand AV assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this document.|

Chief, a brand of Legrand

6436 City West Parkway, Eden Prairie, MN 55344

• P: 800.582.6480 / 952.225.6000 • F:877.894.6918 / 952.894.6918

The PAC115/116/117 hardware kits are designed for use with

Chief® Series Mounts. See the specific installation instructions

provided with the mount for additional installation information.

Unpack and verify kit contents. If any listed parts are missing,

immediately contact a Chief Customer Service representative.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: Failure to read, thoroughly understand, and follow

all instructions can result in serious personal injury, damage to

equipment, or voiding of factory warranty! It is the installer’s

responsibility to make sure all components are properly

assembled and installed using the instructions provided.

WARNING: Failure to provide adequate structural strength for

this product can result in serious personal injury or damage to

equipment! It is the installer’s responsibility to make sure the

structure to which this product is attached can support five times

the combined weight of all equipment. Reinforce the structure as

required before installing the product. The wall to which the mount

is being attached may have a maximum drywall thickness 5/8"

(1.6cm) over steel studs.

WARNING: Exceeding the weight capacity can result in serious

personal injury or damage to equipment! It is the installer’s

responsibility to make sure the combined weight of all

components does not exceed the maximum weight capacity of

the mount being installed. (See mount installation instructions for

weight capacity information.)

WARNING: IMPROPER INSTALLATION CAN LEAD TO

EQUIPMENT FALLING CAUSING SERIOUS PERSONAL

INJURY AND DAMAGE TO EQUIPMENT! DO NOT substitute

hardware. Use only hardware supplied by manufacturer!

WARNING: OVER TIGHTENING OF SCREWS CAN

DAMAGE PARTS AND CAN LEAD TO SERIOUS PERSONAL

INJURY AND DAMAGE TO EQUIPMENT! DO NOT over

tighten screws when installing this product.

WARNING: USING THIS PRODUCT INCORRECTLY MAY

RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO

EQUIPMENT! Do NOT use the PAC115-116-117 to fasten a

mount into only drywall.

WARNING: Use this product only for its intended use as

described in these instructions. Do not use hardware or

attachments not recommended by the manufacturer.

WARNING: Never operate this product if it is damaged. Return

the product to a service center for examination and repair.

WARNING: Do not use this product outdoors.

IMPORTANT ! : The PAC115-116-117 kits may be used to

fasten mounts to a 2" x 4"-25ga minimum steel stud wall.

®Chief is a registered trademark of Legrand AV Inc.

PARTS

1.Reference the instruction manual included with the mount being

installed for complete steel stud installation steps.

(A)

[1/4-20 BB toggler anchor]

(B)

1/4-20 x 1-3/4"

(C)

1/4"

ABC

MODEL(qty)(qty)(qty)

PAC115

444

PAC116

888

PAC117

282828

8800-003402 Rev00

©2024 Legrand AV|

www.legrandav.com

03/2024
