Strona 1/10
Errors excepted; subject to change www.colormetrics.info
P4100
User Manual
Version 1.0
3
www.colormetrics.infowww.colormetrics.info Colormetrics P4100
2
Colormetrics P4100
Copyright 2015 Publishing. All Rights Reserved.
This manual, software and firmware described in it are copyrighted by their respective owners and
protected under the laws of the Universal Copyright Convention. You may not reproduce, transmit,
transcribe, store in a retrieval system, or translate into any language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, biological, molecular, manual, or otherwise,
any part of this publication without the express written permission of the publisher.
All products and trade names described within are mentioned for identification purpose only.
No affiliation with or endorsement of the manufacturer is made or implied. Product names and brands
appearing in this manual are registered trademarks of their respective companies.
The information published herein has been checked for accuracy as of publishing time.
No representation or warranties regarding the fitness of this document for any use are made or implied by
the publisher. We reserve the right to revise this document or make changes in the specifications of
the product described therein at any time without notice and without obligation to notify any person of
such revision or change.
COPYRIGHT SAFETY INSTRUCTIONS
1. Read these instructions carefully. Keep these instructions for future reference.
2. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed
detergent for cleaning. Use moisture sheet or cloth for cleaning.
3. Please keep this equipment from humidity.
4. Lay this equipment on a reliable surface when install. A drop or fall could cause injury.
5. Make sure power cord such a way that people cannot step on it. Do not place anything over the
power cord.
6. All cautions and warnings on the equipment should be noted.
7. If the equipment is not used for long time, disconnect the equipment from main to avoid being
damaged by transient over voltage.
8. Never pour any liquid into opening, this could cause fire or electrical shock.
9. If one of the following situations arises, get the equipment checked by a service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
w. The equipment does not work well or you can not get it work according to user manual.
e. The equipment has dropped and damaged.
10. Do not leave this equipment in an environment unconditioned, storage temperature below -20°C
or above 60°C, it may damage the equipment.
11. Unplug the power cord when doing any service or adding optional kits.
Lithium Battery Caution:
Danger of explosion can happen if the battery is incorrectly replaced, Replace only the original or equivalent
type recommended by the manufacture. Dispose used batteries according to the manufacture’s instructions.
Do not remove the cover, and ensure no user serviceable components are inside. Take the unit to the
service center for service and repair.
4
www.colormetrics.infowww.colormetrics.infoColormetrics P4100
5
Colormetrics P4100
COPYRIGHT 2
SAFETY INSTRUCTIONS 3
1 PACKING LIST 5
1-1. Standard Accessories 5
1-2. Optional Accessories 5
2 SYSTEM VIEW 6
2-1. Rear View (I/O Type A) 6
2-2. Back View 6
2-3. Specification 7
2-4. Internal Layout 8
3 PIN DEFINITION 9
4 REAR I/O INTERFACE 12
5 SYSTEM ASSEMBLY & DISASSEMBLY 13
5-1. HDD 13
5-2. Memory 14
5-3. MSR/i-Button/RFID 15
5-4. VFD/8”/10”/15” 2nd Display 16
5-5. 1D/2D Barcode scanner 19
6 DEVICE DRIVER INSTALLATION 20
6-1. Resistive Type Touch Panel and P-CAP 20
6-2. MagStripe Card Reader Configuration Utility 26
6-3. RFID 35
6-4. USB 2nd Display 41
6-5. Configuration Utility of i-Button Reader 43
6-6. VFD VD1220 49
7 BIOS/UTILITY SETUP 54
7-1. Advanced 55
7-2. Security 57
7-3. Power 58
7-4. Boot 59
7-5. Exit 59
NOTICE 60
8 LCD SURFACE CLEANING 61
TABLE OF CONTENTS
1-1 Standard Accessories
a. b. c.
d. e.
1 PACKING LIST
a. System (with stand)
b. Power Adapter
c. Power Cord
d. Driver Bank
e. Cable D-SUB to RJ45
1-2 Optional Accessories
a. b. c. d.
e. f. g. h.
a. Single MSR
b. 2x 20 VFD (pole or direct mount)
c. 8” - 10“ 2
nd
Display, 15“ 2
nd
Display (pole)
d. 1D or 2D Scanner
e. MSR + iButton
f. MSR + RFID
g. Stand option B
h. Stand option C
