IMPORTANT INSTRUCTIONS Retain these instructions for future reference, read them carefully and note also the

information given on the heater.

IMPORTANT SAFETY INFORMATION

WARNING - THE SURFACE OF THIS HEATER CAN BE HOT.

The surface temperatures of this heater are within the requirements of EN60335, the European Standard covering the safety requirements of

electric storage heating appliances, and momentary contact with any part of the heater should not cause injury. However, in order to be effective,

heaters of any type do get hot, especially around the air outlet grille.

Therefore, if aged or infirm persons, or young children, are likely to be left unsupervised in the vicinity of a heater, precautions should be taken

to ensure that prolonged contact with the heater cannot occur. We recommend that a guard is fitted around the heater, as is normal with some

types of heating appliances in similar circumstances. A range of guards for Creda storage heaters is available. If you require further information

on these guards, please contact Creda Heating (0845) 604 2399.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experi-

ence and knowledge, unless they have been given supervision for instruction concerning use of the appliance by a person responsible for their

safety. Children should be supervised to ensure that they do not play with the appliance.

• DO NOT COVER THE SURFACES OF THE HEATER AND DO NOT OBSTRUCT AIR OUTLET GRILLES Surfaces of the heater should not be

covered or obstructed as this can cause excessive temperatures that can be hazardous and may cause safety cut-outs to operate. For example,

do not put clothes, fabrics or any combustible materials on the heater or allow curtains to come within 250mm (10”) of the top of the heater

and 75mm (3”) of the ends of the heater, and do not allow furniture to be pushed up against the heater.

• DO NOT ATTEMPT TO MOVE THE HEATER. YOUR STORAGE HEATER IS VERY HEAVY. For safety in use the heater must be securely fixed

to a sound wall and specialist advice must be sought before moving. If you are not happy that the heater has been securely fixed, please

inform your installer.

• DO NOT SIT OR STAND ON THE HEATER.

• DO NOT SPILL LIQUIDS ONTO THE APPLIANCE. IF YOU DO, SWITCH THE HEATER OFF AND GET A QUALIFIED ELECTRICIAN TO

CHECK IT.

• DO NOT POKE OBJECTS THROUGH THE GRILLE OR VENTILATION SLOTS.

• DO NOT USE POLISHES ON THE HEATER OR ON FURNITURE NEAR TO IT.

• The hot interior of the heater can produce paraffin smells from polish vapours which may last for a number of hours.

• DO NOT ATTEMPT TO REPAIR THE HEATER YOURSELF. In case of breakdown or other failure, switch off the heater at the wall switch and

consult your supplier, local electricity company or Creda Heating. Always ensure that the heater is switched off at the wall switch and the

fuse removed before any repair is carried out.

Creda TSR Fanned Combi heaters store heat on the off peak tariff and discharge the stored heat gradually throughout the day. In addition

to the storage heater function the Fanned Combi heater has a fan heater fitted below the storage heater that allows you to boost the normal

output, coping with sudden changes in weather. Also, in summer when the storage heater part has been switched off, you can use the fan

heater for heat on an occasional chilly day. Note that the fan heater uses normal price electricity and will therefore be more expensive to run

than the storage heater alone.

FIRST HEATING OF A NEW HEATER:

The new heater will give off a smell. It is recommended the dispersion of this smell should be accelerated by running the heater straight up to

its maximum temperature, whatever the prevailing weather.

Set the Input control knob to the maximum setting of 6 and the Output control knob to the maximum setting of 6 and run the heater like this

for two nights. The instructions to the installer of your heater mentions this and he will probably set it for you. The smell is normally harmless

in a ventilated room and if possible, a window should be left open during the overnight charging periods. Caged birds, young children and

people with chest ailments are best kept out of the room during the first period.

USING YOUR HEATER:

Your heater will be one of two types: either one with automatic control of the overnight charge or alternatively, one on which you adjust this

manually from time to time. If necessary, check which heater you have, by looking at the model number located on the wall fixing angle.

Heaters with model numbers 75772001S, 75772002S or 75772003S are automatic heaters, all other heaters require manual adjustment. The

heaters store heat overnight while the cost of Economy 7 electricity is cheaper and discharge the heat gradually throughout the following day.

CONTROLS:

There are two control knobs located under the lockable flap at the right hand

corner of the top panel. Think of these as input (storage charge) and output

(room temperature for fan heater).

NOTE: If, during any reassembly of the heater a part of the thermal insulation

shows damage or deterioration which may impair safety, it should be replaced

by an identical part.

TSR SUPASLIM COMBI

Combined Storage and Fan Heaters

Owners Guide

Manual Automatic

Model Nos: 79348S 79358S 79368S 75772001S 75772002S 75772003S

Cat. Nos: TSR12CW TSR18CW TSR24CW TSR12ACW TSR18ACW TSR24ACW

SHELVES:

A shelf positioned above the heater will enable this space to be used because,

as described earlier, it is not safe to place anything actually on the heater itself. Also, a shelf will cut down the dust streaking on the wall which

sometimes results from the warm air rising from wall mounted radiators of all types. A purpose built range of shelves to suit the TSR Combi

heaters are available from your heater stockists or direct from Creda Heating.

3.4kW heater shelf pack 79062, 2.6kW heater shelf pack 79052, 1.7kW heater shelf pack 79042
