Installation and Operation Manual
THE EXPERTS IN ROOM AIR CONDITIONING
115 VOLT CCV15
230 VOLT CCV18, CCV24
Chassis Models
93011012_01
Table of Contents
Other Features
...............................................................................................................................
19
IMPORTANT SAFETY INSTRUCTIONS
....................................................
1
What’s in the Box
...............................................................................................................................
4
Introduction 5
Operating Instructions
............................................................................................................................
6
8Setup & Installation
...............................................................................................................................
18
Maintenance
..............................................................................................................................
20
...............................................................................................................................
Trouble shooting
..............................................................................................................................
1
IMPORTANT SAFETY INSTRUCTIONS
Before installing and using your air conditioner, please read this owner’s manual carefully. Store
this manual in a safe place for future reference.
Your safety and the safety of others is very important to us. Please pay attention to all safety
messages outlined in this owner’s manual.
WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner,
follow the following basic precautions:
ELECTRICAL REQUIREMENTS
The electrical ratings for your air conditioner are listed on the model and serial number label
located on the front right hand side of theunit (when facing the front).
REGISTER YOUR APPLIANCE
You can register your appliance online by going to register.tcl.com
Be sure to retain your original sales receipt. A valid proof of purchase is required for all warranty
claims.
BATTERY WARNING STATEMENT
Do not mix old and new batteries and do not mix alkaline, standard (carbon-zinc) or rechargeable
(ni-cad, ni-mh, etc.) batteries
RECOMMENDED GROUND METHOD
For your personal safety, this air conditioner must be grounded. This air conditioner is equipped
with a 3 prong power supply cord with a grounded plug. To minimize the possibility of electrical
shock, the cord must be plugged into a 3 prong outlet and grounded in accordance with all local
codes and ordinances. If a 3 prong outlet is not available,it is the customer’s responsibility to
have a properly grounded 3 prong outlet installed by a qualified electrician.
contact us first
with any questions
WE ARE
REA DY TO
HELP
BE CA REF L HE R
EMOVING
THE A IR CO DITIONING UNIT
Document your model and serial numbers here:
Model #__________________________ Serial #________________________________
You can locate your 20 digit serial number underneath the bar code (On the right hand side
of the AC).
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong.
Do not use an adapter
Do not use an extension cord.
Failure to follow these instructions
can resultin death, fire, or electrical
shock
• 115V(103min-127max)
• (15K) (0-15 amps)
• (15K) (15 amp time-delay fuse or circuit breaker)
• 208/230V(187min-253max)
• (18K) (0-13 amps)
• (24K) (0-20 amps)
• (18K) (15 amp time-delay fuse or circuit breaker)
• (24K) (20 amp time-delay fuse or circuit breaker)
• Use on single outlet circuit only
Wiring Requirements Power Supply Cord
WARNING
Specific electrical requirements are shown in the
diagram below.Follow there quirements below for the
type of plug on the power supply cord.
