Strona 1/42
INSTRUCTION MANUAL
Ver：1.00
AW-3SD
CONTENTS
1. GENERAL .......................................................................................... 1
1-1. Specications of AW-3SD .............................................................................................. 1
1-2. Conguration .................................................................................................................. 2
2. INSTALLATION 4 ..................................................................................
2-1. Installing the AW-3SD ..................................................................................................... 4
2-2. Installation location ........................................................................................................ 4
3. OPERATION PROCEDURE 5 ...............................................................
3-1. Opening/closing the cover door .................................................................................... 5
3-2. Removing the device cover ........................................................................................... 6
3-3. How to thread the device with the bobbin thread ........................................................ 7
3-4. How to set a bobbin ........................................................................................................ 9
3-5. Length of remaining thread to be removed ................................................................ 11
3-6. Device operation lamp .................................................................................................. 11
3-7. Behavior of the AW-3SD device when the power is turned ON ................................ 12
3-8. Program mode list ........................................................................................................ 12
3-9. Basic operation and setting ......................................................................................... 15
3-10. Operating the AW ........................................................................................................ 16
3-11. Setting the AW number-of-stitches input mode, AW operation mode and
remaining-thread allowance length ......................................................................... 19
3-12. Example of operation ................................................................................................. 24
3-13. Turning OFF of the power .......................................................................................... 29
3-14. Error display and error handling procedure ............................................................ 29
3-15. Detection of errors related to the AW ........................................................................ 31
3-16. List of errors ................................................................................................................ 32
3-17. Cautions ....................................................................................................................... 33
4. MAINTENANCE 34 ...............................................................................
4-1. Attaching / removing the cover ................................................................................... 34
4-2. Cleaning ......................................................................................................................... 35
4-3. Replacing the fuse ........................................................................................................ 37
4-4. Replacing the gripper tube .......................................................................................... 37
4-5. Adjusting the air ow for the remaining thread guide .............................................. 38
5. TROUBLESHOOTING 39 .....................................................................
– 1 –
1. GENERAL
1 Applicable bobbin, bobbin case Exclusive double-capacity bobbin and bobbin case.
2 Applicable thread count #5 to #30 (Japan), 135 to 45 (TEX), 020 to 060 (TKT)
3 Applicable type of thread Synthetic thread
4 Remaining-thread removal and
bobbin winding operation
Possible while the sewing machine is in operation.
5Condition setting according
to the thread type
Conditions to be met to unravel the thread at the beginning of wind-
ing a bobbin can be set.
6Line voltage 200,220,240 Vac ±10 %, Single phase 50/60 Hz
7Power consumption 100 VA
8Air pressure used 0.4 to 0.5 MPa
* Adjustment of the air pressure may be required depending on the
thread to be used. (The air pressure for the AW-3SD has been
factory-set to 0.5 MPa at the time of shipment.)
9Air consumption 156 Nℓ / min (max. value)
10 Dimensions
700 mm (W
)
× 650 mm (L
)
× 430 mm
(H
) (Accessories included)
11 Mass of the device 38 kg
12
Operating temperature range
5 ˚C to 35 ˚C
13
Operating humidity range
35 % to 85 % (No dew condensation)
14 Noise - Equivalent continuous emission sound pressure level (L
pA) at
the workstation : A-weighted value ≦ 80.0 dB ; (Includes KpA =
2.5 dB) ; according to ISO 10821- C.6.2 -ISO 11204 GR2.
Conventionally, a series of operations including the replacement of a bobbin in the sewing machine hook,
removal of thread remaining on a bobbin, winding of a bobbin, threading of the bobbin case tension spring,
threading of the thread guide claw hole and trimming of thread have been carried out manually. Now, this
device is developed to carry out the series of operations full-automatically. This device is provided with new
functions in addition to the conventional AW-3's functions, thereby not only helps increase eciency of sew-
ing work but also improves convenience.
Refer to the technical data on the JUKI industrial computer-controlled sewing machine PLK-J, "Sewing
machine head", "Operation panel" and "Control device" for information about the main body of the sewing
machine.
1-1. Specications of AW-3SD
