RSW-10
S P E C I F I C A T I O N S
ENCLOSURE TYPE 10'' Bass-reflex via 10'' passive radiator
AMPLIFIER BASH digital hybrid
FTC Rated Power: 385 watts continuous @ <1%THD
Dynamic Power*: 1150 watts @ <1%THD
AUTO POWER 2 second ON delay, 15 minute OFF delay
BANDWIDTH 29-120Hz ± 3dB
MAXIMUM OUTPUT 109dB @ 30Hz 1/8 space, 1 meter
LOW PASS Continuously v iable from 40-120Hzar
CROSSOVER 36dB/octave slope above 120Hz
INPUTS Two line level RCA phono jacks, low pass
enable/disable switch for LFE mode
OUTPUTS Two line level RCA phono jacks (unfiltered)
PHASE Switchable 0-180 degrees
DRIVE COMPONENTS One 10'' (25.4cm) Cerametallic cone woofer
and one 10'' (25.4cm) Cerametallic cone
passive radiator
NET WEIGHT 45 lbs. (20.4kg)
HEIGHT 14.2" (36.1cm)
WIDTH 13.6" (34.5cm)
DEPTH 19.5" (49.5cm) w/grille, 18''(45.7cm)
w/o grille
FINISH Black Ash woodgrain vinyl
VOLTAGE 110/120 VAC 60Hz
EXPORT VERSION N/A
Dual 10'' Powered Subwoofer
Compact and powerful, the RSW-10 powered
subwoofer extends and intensifies the bass
output of any music or home theater system.
Its built-in electronic crossover provides all the
flexibility necessary to achieve a seamless
blend with the main speakers, whether small
satellites that depend on the subwoofer to
shoulder the entire low-frequency load or full-
range models that need only bottom-end
reinforcement.
The RSW-10 has a rear-firing active driver with
a rigid, low resonance cast aluminum frame
and a front-mounted passive radiator, both
with 10-inch Cerametallic™ cones. The active
driver’s large magnet structure and high-
temperature voice coil enable it to deliver rich,
clean, pulse-pounding bass to below 30Hz. It
is powered by a high-efficiency BASH
®digital
hybrid amplifier, capable of 1150 watts
dynamic output. The passive radiator enables
the RSW-10 to generate very deep bass from
a relatively small enclosure.
The RSW-10’s low-pass crossover has an
exceptionally steep 36dB/octave slope, a
continuously variable frequency control, and
a ph a s e sw i t c h , fa c i l i t a t i n g sm o o t h
speaker/subwoofer integration. A bypass
switch allows direct connection to the
subwoofer amplifier for use with the crossover
built into an A/V preamp or receiver. The
RSW-10’s level control is mounted on the
side of the cabinet for easy access. Input is line-
level via a stereo pair of RCA jacks; another
pair of RCA jacks provides unfiltered output
for connection to a second subwoofer or
other component. An “auto power” feature
enables the subwoofers to turn on and off
automatically.
Dynamic power indicates the actual power this amplifier will deliver to the woofer under normal operating
conditions. While the FTC power rating indicates power available on a continuous, long-term basis, subwoofers
do not rely on that type of power. Instead, the amplifier is called upon to deliver large, short-term peaks of
power to be able to support the wide dynamics required by today’s digital music and movie formats. In
addition to the required FTC power rating, we’ve provided the dynamic power rating as a better indication of
the product’s true performance.
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2004
*
■ Cerametallic cone driver and passive radiator, cast-aluminum frames
■ High-efficiency BASH digital hybrid amplifier
■ Steep-slope 36dB/octave crossover filter with bypass option
■ Side-mounted level control for easy adjustment
■ Auto power feature turns sub on and off automatically
