CATALYST CX FAMILY

CATALYST CX 200

CATALYST CX 100

CATALYST CX 60

PILOT’S GUIDE

2 3

Line 6, the Line 6 logo, Catalyst, Helix, HX, HX Stomp, POD Go are trademarks or registered trademarks of Yamaha Guitar Group, Inc. in the U.S. and/or other jurisdictions. Apple, iPhone,

iPod, Lightning, and macOS are trademarks of Apple Inc., registered in the U.S. and other countries and regions. Apple is not responsible for the operation of this device or its compliance

with safety and regulatory standards. iOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license. Android and Google Play are trademarks

of Google LLC. Windows is a trademark of Microsoft Corp. registered in the U.S. and other countries.

SERIAL NO.: ___________________________________

MODEL NO.: ___________________________________

Supplier’s Declaration of Conformity

47 CFR § 2.1077 Compliance Information

Unique Identiﬁers: Line 6

Catalyst

CX 200, Catalyst

CX 100, Catalyst

CX 60.

Responsible Party - U.S. Contact Information:

Yamaha Guitar Group, Inc.

26580 Agoura Road

Calabasas, CA 91302-1921

(818) 575-3600

https://line6.com/

FCC Compliance Statement:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

2 3

CATALYST CX COMPARISON

FEATURES CATALYST CX 200 CATALYST CX 100 CATALYST CX 60

Ampliﬁer Wattage

200 Watts 100 Watts 60 Watts

Power Damping

Full Power, Half Power, 0.5 Watts, Mute

Speakers

2x12" custom voiced 1x12" custom voiced 1x12" custom voiced

Number of Channels

Amp Voicings

Instrument Inputs

1 x 1/4"

3-Band

Controls

Boost, Gain, Presence, Channel Volume, Master Volume

Digital Effects

6 types of each Delay, Modulation, Pitch/Filter, and Reverb eects - two dierent types of eects can be enabled simultaneously and

each edited independently

Tap Tempo

Yes

Tuner

Yes

FX Loop

Yes

Aux In

3.5 mm

Headphone Out

1/4"

Direct Out

XLR w/ground lift

USB Audio Interface

4-in/4-out

Power Amp In

1/4" (via FX Loop Return)

MIDI

5-Pin DIN or USB USB

Software

Catalyst Edit - Remote software editor (PC, Mac, iOS, Android)

Weight

41.6 lbs / 18.9 kg 31.9 lbs / 14.5 kg 25.9 lbs / 11.8 kg

Dimensions

(H x W x D)

19.2 x 27.3 x 10.3 inches

488 x 694 x 262 mm

19.8 x 22.2 x 10.3 inches

488 x 564 x 262 mm

17.5 x 19.8 x 10.3 inches

444 x 503 x 262 mm

Accessories

(sold separately)

LFS2 Footswitch (Channel A/B, Eects on/o)

Catalyst 200 Cover Catalyst 100 Cover Catalyst 60 Cover

NOTE: All features above are also available in ﬁrst generation Line 6 Catalyst 200, 100, and 60 ampliﬁers with version 2.0 or later ﬁrmware installed.
