McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 www.mcintoshlabs.com
C2800C2800
TUBE PREAMPLIFIER
OWNER’S MANUAL
2
Trademark and License Information
The McIntosh C2800 incorporates copyright
protected technology that is protected by U.S.
patents and other intellectual property rights. The
C2800 uses the following technologies:
Trademark License Information
ASIO is a trademark and software
of Steinberg Media Technologies
GmbH
Manufactured under license
from Dolby Laboratories. Dolby,
Dolby Audio, and the double-D
symbol are trademarks of Dolby
Laboratories.
For DTS patents, see http://patents.
dts.com. Manufactured under
license from DTS, Inc. DTS, the
Symbol, DTS and the Symbol
together, and Digital Surround
are registered trademarks and/
or trademarks of DTS, Inc. in
the United States and/or other
countries. DTS, Inc. All Rights
Reserved.
HIGH-DEFINITION MULTIMEDIA INTERFACE
TM
The terms HDMI, HDMI
High-Denition Multimedia
Interface, and the HDMI Logo
are trademarks or registered
trademarks of HDMI Licensing
Administrator, Inc.
Thank You from all of us at McIntosh
You have invested in a precision instrument that
will provide you with many years of enjoyment.
Please take a few moments to familiarize yourself
with the features and instructions to get the
maximum performance from your equipment.
If you need further technical assistance, please
contact your dealer who may be more familiar with
your particular setup including other brands. You
can also contact McIntosh with additional questions
or in the unlikely event of needing service.
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Technical Assistance (607) 723-3512
Fax (607) 724-0549
Customer Service (607) 723-3515
Fax (607) 723-1917
Email support@mcintoshlabs.com
Website www.mcintoshlabs.com
Please Take A Moment
For future reference, you can write down your
serial number and purchase information here. We
can identify your purchase from this information if
the occasion should arise:
Serial Number: __________________________
Purchase Date: ___________________________
Dealer Name: ___________________________
Safety First
Please read the safety instructions included in a
separate document called Important Additional
Operation Information Guide.
Table of Contents
Trademark and License Information . .. .. .. 2
Introduction . .. .. .. .. .. .. .. .. .. .. .. .. .. 3
General Information .. .. .. .. .. .. .. .. .. .. 3
Connector and Cable Information.. .. .. .. .. 3
Performance Features.. .. .. .. .. .. .. .. .. .. 4
Dimensions .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5
Installation .. .. .. .. .. .. .. .. .. .. .. .. .. .. 5
Front Panel Knobs and Buttons.. .. .. .. .. .. 6
Inputs .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 7
Outputs.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 7
How to use the Remote Control .. .. .. .. .. .. 9
Setup Menus ........................10-11
Digital Setup Menu .. .. .. .. .. .. .. .. .. .12-13
Inputs Setup Menu .. .. .. .. .. .. .. .. .. .. ..13
Outputs Setup Menu .. .. .. .. .. .. .. .. .. .. 14
Triggers Setup Menu .. .. .. .. .. .. .. .. .. ..15
Data Out Setup Menu .. .. .. .. .. .. .. .. .. ..15
External Control Setup Menu. .. .. .. .. .. ..16
System Configuration .. .. .. .. .. .. .. .. .. ..17
Connecting Components.. .. .. .. .. .. .. .. .. 17
Trim Functions Menu.. .. .. .. .. .. .. .. .18-19
Tone Control . .. .. .. .. .. .. .. .. .. .. .. .. ..19
Network Information Menu .. .. .. .. .. .. ..19
How to Operate the C2800 .. .. .. .. .. .. 20-25
Specifications .. .. .. .. .. .. .. .. .. .. .. .. ..26
Packing Instructions .. .. .. .. .. .. .. .. .. ..27
Parts List .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..27
3
C2800
Connector and Cable Information
XLR Connectors
Pin conguration for the XLR Balanced Input
and Output Connector. Refer to the diagrams for
connections:
PIN 1: Shield/Ground
PIN 2: + Input/Output
PIN 3: - Input/Output
Power Control and Trigger Connectors
The C2800 Power Control Out,
Trigger and PASSTHRU Output
Jacks send Power On/Off Signals (+12
volt/0 volt) when connected to other
Components. An additional connec-
tion is for controlling McIntosh Power Ampliers
Output Meters. A 3.5mm stereo mini phone plug is
used for connection to the Power Control (Trigger)
and PASSTHRU Output.
Note: A complete line of custom McIntosh power control cables
are available, starting with the “CC1M” 1-meter cable.
Data Port Connectors
The C2800 Data Out Ports send
Remote Control Signals to Source
Components. A 3.5mm stereo mini
phone plug is used for connection.
IR IN Port Connectors
The IR IN Port also uses a 3.5mm
stereo mini phone plug and allows
the connection of other brand IR
Receivers to the C2800.
RS232 Data Port Cable
The RS232-C Data Cable is a 3.5mm stereo mini
phone plug used to connect
to external third party
controllers.
Data
Signal
N/C
Data
Ground
PIN 2 PIN 1
PIN 3
PIN 1
PIN 2
PIN 3
Power
Control
Meter
Illumination
Control
Ground
Main, Triggers 1-4
and PAS STH RU
IR Data
Control
Ground
N/C
General Information
1. Do not apply AC Power to the C2800 and other
Component(s) until they are connected to the
C2800 so operational malfunctioning does not
occur.
2. Balanced and Unbalanced Inputs and Outputs can
be mixed. For example, you may connect signal
sources to Unbalanced Inputs and send signals
from the Balanced Outputs. You can also use
Balanced and Unbalanced Outputs simultaneously,
connected to different Power Ampliers.
3. The C2800 internal Digital to Analog Converter
Circuitry is designed to decode PCM, DSD and
DTS Digital Signals. The Coaxial and Optical
Digital Audio Inputs are for PCM Digital Signals,
Dolby Signals and DTS Signals. The C2800 also
decodes USB and HDMI (ARC) Digital Signals.
Other Digital Audio Signal Format Types will
cause the Audio Outputs of the C2800 to be muted.
4. The McIntosh C2800 is factory congured for
immediate use. It can also be customized to
complement the components making up your
system. Refer to the Setup Menu described on page
11.
5. The Remote Control Supplied with the C2800
Preamplier is capable of operating other compo-
nents. For additional information go to www.
mcintoshlabs.com.
6. The Rear Panel IR Input is congured for
non-McIntosh IR sensors such as a Xantech Model
DL85K Kit. When in use, consider turning Off the
Front Panel sensor to avoid interference.
7. The C2800 has been tested and certied for indoor
use only.
8. For additional information on the C2800 and
other McIntosh Products please visit the McIntosh
website at www.mcintoshlabs.com.
C2800 TXD Out
Data being transmitted
C2800 RXD In
Data being received
Ground
Introduction
The McIntosh C2800 Tube Preamplier is one of
the nest Preampliers ever created with connec-
tions for both analog and digital sources. The
C2800 Outputs have the ability to drive multiple
Power Ampliers. The C2800 reproduction is
sonically transparent and absolutely accurate.
The McIntosh Sound is “The Sound of the Music
Itself.”
