Instrukcja obsługi Smeg KDD60VXE-3
Smeg
Okap wyciągowy
KDD60VXE-3
Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Smeg KDD60VXE-3 (5 stron) w kategorii Okap wyciągowy. Ta instrukcja była pomocna dla 16 osób i została oceniona przez 8.5 użytkowników na średnio 4.4 gwiazdek
Strona 1/5
KDD90CNE - KDD90CNE2
KDD60VXE-2 - KDD60VXE-3
KDD90VXE-2 - KDD90VXBE
KDD90VXNE - KDD90VXSE
IT
LIBRETTO DI USO
EN
USER MANUAL
FR
MANUEL D’UTILISATION
DE
BEDIENUNGSANLEITUNG
NL
GEBRUIKSAANWIJZING
ES
MANUAL DE USO
PT
LIVRO DE INSTRUÇÕES PARA UTILIZAÇÃO
RU
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
SV
BRUKSANVISNING
DA
BRUGSVEJLEDNING
PL
INSTRUKCJA UŻYTKOWANIA
NO
BRUKSVEILEDNING
FI
KÄYTTÖOHJEET
AR
8
1. SAFETY
INFORMATION
For your safety and correct
operation of the appliance, read
this manual carefully before
installation and use. Always keep
these instructions with the appliance
even if you move or sell it. Users
must fully know the operation and
safety features of the appliance.
The wire connection has to be
done by specialized technician.
• The manufacturer will not be
held liable for any damages
resulting from incorrect or improper
installation.
• If the instructions for installation
of the gas hob specify a greater
distance, this must be respected.
• Check that the mains voltage
corresponds to that indicated on
the rating plate xed to the inside
of the hood.
• Means for disconnection must be
incorporated in the xed wiring in
accordance with the wiring rules.
• For Class I appliances, check
that the domestic power supply
guarantees adequate earthing.
• Connect the extractor to the
exhaust ue through a pipe of
minimum diameter 120 mm. The
route of the ue must be as short
as possible.
• Regulations concerning the
discharge of air have to be fullled.
• Do not connect the extractor
hood to exhaust ducts carrying
combustion fumes (boilers,
replaces, etc.).
• If the extractor is used in conjunction
with non-electrical appliances
(e.g. gas burning appliances),
a sucient degree of aeration
must be guaranteed in the room
in order to prevent the backow
of exhaust gas. When the cooker
hood is used in conjunction with
appliances supplied with energy
other than electric, the negative
pressure in the room must not
exceed 0,04 mbar to prevent
fumes being drawn back into the
room by the cooker hood.
• The air must not be discharged into
a ue that is used for exhausting
fumes from appliances burning
gas or other fuels.
• If the supply cord is damaged,
it must be replaced from the
manufacturer or its service agent.
• Connect the plug to a socket
complying with current regulations,
located in an accessible place.
• With regards to the technical and
safety measures to be adopted
for fume discharging it is important
to closely follow the regulations
provided by the local authorities.
WARNING: Before installing
the Hood, remove the protective
lms.
• Use only screws and small parts
supplied with the hood.
WARNING: Failure to install
the screws or xing device in
accordance with these
instructions may result in
EN
9
electrical hazards.
• Do not look directly at the light
through optical devices (binoculars,
magnifying glasses…).
• Do not ambè under the range
hood; risk of re.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.
• Children should be supervised to
ensure that they do not play with
the appliance.
• The appliance is not to be used
by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack
of experience and knowledge,
unless they have been given
supervision or instruction.
Accessible parts may become
hot when used with cooking
appliances.
• Clean and/or replace the Filters
after the specied time period (Fire
hazard). See paragraph Care and
Cleaning.
• There shall be adequate ventilation
of the room when the range hood
is used at the same time as
appliances burning gas or other
fuels (not applicable to appliances
that only discharge the air back
into the room).
• The symbol on the product
or on its packaging indicates
that this product may not be
treated as household waste.
Instead it shall be handed over
to the applicable collection point
for the recycling of electrical
and electronic equipment. By
ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences
for the environment and human
health, which could otherwise be
caused by inappropriate waste
handling of this product. For
more detailed information about
recycling of this product, please
contact your local city oce,
your household waste disposal
service or the shop where you
purchased the product.
• This suction Hood can be used
in combination with a Gas hob
with the following characteristics:
• Total maximum power 12.4kW.
• 5 burners as shown in the gure.
2,6 kW
1 kW
5 kW
1,9 kW
1,9 kW
• Total maximum power
11,5kW.
Specyfikacje produktu
| Marka: | Smeg |
| Kategoria: | Okap wyciągowy |
| Model: | KDD60VXE-3 |
