Swift Kon-Tiki
Technical Handbook
Swift Group
Dunswell Road
Cottingham
East Yorkshire HU16 4JX
Tel 01482 847332
Fax 01482 841042
email enquiry@swiftgroup.co.uk
For more information visit
www.swiftgroup.co.uk
Issued July 2014
1410348
1
Contents
Specifications ............................................................................. 2
Capacities ................................................................................. 10
Towing Capabilities .................................................................. 12
Jacking ..................................................................................... 14
Wiring Diagrams ....................................................................... 15
Bulb Chart ................................................................................. 21
Bulb Replacement ...................................................................... 22
2 3
Specifications
Kon-Tiki 635 Kon-Tiki 635 Option
Low Line Low Line
150 MJT 150 MJT Auto 180 MJT 180 MJT Auto
2287cc 2287cc 2999cc 2999cc
109kW @ 3600rpm 109kW @ 3600rpm 130kw @ 3500rpm 130kw @ 3500rpm
350Nm @ 1500rpm 350Nm @ 1500rpm 400Nm @ 1400rpm 400Nm @ 1400rpm
Fiat AL-KO low line Fiat AL-KO low line
4.60m /15' 1" 4.60m /15' 1"
3 3
4 4
8.06m/ 26' 5" 8.06m/ 26' 5"
2.35m/ 7' 8" 2.35m/ 7' 8"
2.98m/ 9' 9" 2.98m/ 9' 9"
4250kg 4250kg
3751kg* 3768kg* 3801kg* 3818kg*
499kg* 482kg* 449kg* 432kg*
3575kg* 3592kg* 3625kg* 3642kg*
9kg 9kg
THREE THREE
2.04m x 0.91m/ 6'8" x 3'0" 2.04m x 0.91m/ 6'8" x 3'0"
2.03m x 1.23m/ 6'8" x 4'0" 2.03m x 1.23m/ 6'8" x 4'0"
1.87m x 0.71m/ 6'2" x 2'4" 1.87m x 0.71m/ 6'2" x 2'4"
1.87m x 0.71m/ 6'2" x 2'4" 1.87m x 0.71m/ 6'2" x 2'4"
Model Kon-Tiki 625 Kon-Tiki 625 Option
Roof Profile Low Line Low Line
Engine 150 MJT 150 MJT Auto 180 MJT 180 MJT Auto
Engine Capacity 2287cc 2287cc 2999cc 2999cc
Max Power 109kW @ 3600rpm 109kW @ 3600rpm 130kw @ 3500rpm 130kw @ 3500rpm
Torque 350Nm @ 1500rpm 350Nm @ 1500rpm 400Nm @ 1400rpm 400Nm @ 1400rpm
Chassis Fiat AL-KO low line Fiat AL-KO low line
Wheel base
4.60m /15' 1" 4.60m /15' 1"
Designated Passenger Seats 3 3
Berths (sleeping positions) 4 4
Overall Length** 8.06m/ 26' 5" 8.06m/ 26' 5"
Overall Width (mirrors folded) 2.35m/ 7' 8" 2.35m/ 7' 8"
Overall Height*** 2.98m/ 9' 9" 2.98m/ 9' 9"
Maximum Technical Permissible Laden
Mass (A)
4250kg 4250kg
Mass in Running Order (B) 3716kg* 3733kg* 3766kg* 3783kg*
Maximum User Payload (A-B) 534kg* 517kg* 484kg* 467kg*
Unladen Weight 3540kg* 3557kg* 3590kg* 3607kg*
Essential Habitation Equipment 9kg 9kg
Thermal Insulation Grade THREE THREE
Bed Sizes
Front Double 2.08m x 1.17m/ 6'10" x 3'10" 2.08m x 1.17m/ 6'10" x 3'10"
Front Offside Single
Rear Double 1.86m x 1.30m/ 6'1" x 4'3" 1.86m x 1.30m/ 6'1" x 4'3"
Rear Offside Single
Rear Nearside Single
Overcab Bed
NOTE: 1. The Maximum User Payload includes:
a) the conventional load (this is the allowance for
passengers)
b) essential habitation equipment (items and
fluids required for safe and proper functioning of
habitation equipment)
c) optional equipment (items available from
the manufacturer over and above the standard
specification)
d) personal effects (those items not covered by
the above)
2. The Mass in Running Order is the mass of the
unladen vehicle including a 75kg allowance for the
driver plus engine coolants and 90% of the fuel tank
and 100% gas capacity.
The MRO is calculated with the fresh water tank
empty on all layouts and with one 13kg LPG cylinder
(625 & 635 only).
If you travel with water in the fresh water tank then
the payload will reduce accordingly.
There is provision for a second 13kg LPG cylinder
within the payload allowance should the customer
choose to utilise it.
3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE
ALLOWED FOR THE MASSES OF ALL ITEMS YOU
INTEND TO CARRY IN THE MOTOR CARAVAN,
e.g. passengers, optional equipment, essential
habitation equipment and personal effects, such
as clothing, food, pets, bicycles, sailboards, sports
equipment etc.
4. WARNING - UNDER NO CIRCUMSTANCES
SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE
LADEN MASS OF THIS MOTOR CARAVAN BE
EXCEEDED.
* Estimated
** Add 120mm to length if ladder option fitted.
*** Add 100mm to height on low line if ladder
option fitted.
