Strona 1/41
- 1 -
Content
Content ............................................................................................................................... 1
1 Overview ....................................................................................................................... 2
2 How to use the CLI ....................................................................................................... 3
2.1 Accessing the CLI .................................................................................................... 3
2.1.1 via SSH .............................................................................................................. 3
2.1.2 via Terminal in Controller .................................................................................. 5
2.2 Conventions .............................................................................................................. 6
3 Debug Commands ......................................................................................................... 7
3.1 cliclientd reset ....................................................................................................... 7
3.2 restart ..................................................................................................................... 8
3.3 iwconfig ................................................................................................................. 8
3.4 ifconfig ................................................................................................................ 13
3.5 iwlist .................................................................................................................... 13
3.6 iperf ..................................................................................................................... 16
3.7 cliclientd setctrladdr “inform_url” ...................................................................... 18
3.8 cliclientd wltool scan ........................................................................................... 19
3.9 cliclientd wltool sta ............................................................................................. 20
3.10 cliclientd wltool interface .................................................................................... 22
3.11 cliclientd (ping) ................................................................................................... 23
3.12 cliclientd (tcpdump) ............................................................................................ 25
3.13 cliclientd debug “hostapd” .................................................................................. 27
3.13.1 cliclientd debug “hostapd log_level” ........................................................... 27
3.13.2 cliclientd debug “hostapd log_type” ............................................................ 29
3.13.3 cliclientd debug “hostapd log_size” ............................................................. 31
3.14 cliclientd debug “hostapd_cli get_ptk” ............................................................... 33
3.15 dmesg .................................................................................................................. 36
4 Public commands ........................................................................................................ 39
4.1 top ........................................................................................................................ 39
4.2 ps ......................................................................................................................... 41
- 2 -
1 Overview
TP-Link Omada/Omada Pro/Festa EAPs provide Command Line Interface (CLI) for
debugging. This guide introduces detailed information about the debug commands to facilitate
troubleshooting and locating the fault when the EAP encounters an exception.
With these commands, you can:
1. Perform channel scanning to analyze the Wi-Fi environment; view the wireless
information, including the settings and statistics of the EAP’s wireless interfaces, and
the statistics of clients, etc.
2. Invoke built-in tools, including ping, tcpdump, iPerf.
3. Manage the hostapd logs: determine the level of logs to be outputted, the output
method, and the size of log files to be saved in /tmp/logdump.
Currently, all EAPs that are still being updated and maintained (that is, not in EOL status)
apply to the commands in this document to varying degrees. If you encounter some commands
that do not take effect as described in the guide during the use of these commands, please keep
an eye on the TP-Link official website to upgrade your device to the latest firmware released if
possible. If it still doesn’t work, you can report it to the TP-Link Technical support center or
R&D department. We will provide you with timely assistance and guidance.
Kindly note: the commands displayed in the terminal by entering cliclientd -h may be not
supported completely by the device you are using, please refer to this document for specific
support of the device. In the future, if the commands supported by EAP are added or improved,
we will update them simultaneously in this document.
- 3 -
2 How to use the CLI
2.1 Accessing the CLI
2.1.1 via SSH
1. Enable SSH Login first
(1) If the EAP is managed in standalone mode, please access its web page and go to
Management > SSH to enable SSH Login and set a proper value for Server Port.
Figure 2-1 Enable SSH login in Standalone web
(2) If the EAP is managed via Controller, then go to Site’s Settings > Services > SSH to perform
the relevant operations.
Figure 2-2 Enable SSH login in Controller
Kindly note: If the host PC from which you access EAP via SSH is not on the same
LAN as the EAP, please make sure to enable Layer-3-Accessibility, as well as ensuring
they are accessible to each other.
