SFP+ Single Mode LC Module (20km)

TEG-10GBS20 (v1.xR)

• Transmission distance of up to 20km (12.42 mi.)

• Duplex LC optical interface

• Supports data rates of up to 10.31Gbps

• Supports 1310nm single mode network transmissions

• Low Electromagnetic Interference (EMI) design

• Compliant with IEEE 802.3ae 10 Gigabit Ethernet

• Digital Diagnostics Monitoring (DDM) support

• Small Form-Factor Pluggable (SFP+) and Multi-Source Agreement (MSA) compliant

• Low power consumption

• Lifetime Warranty

• NDAA / TAA compliant (U.S. and Canada only)

TRENDnet’s SFP+ Single Mode LC Modules are compatible with standard SFP+ slots found on network switches and ﬁber

converters. Each single mode 10G SFP+ transceiver is equipped with a duplex LC ﬁber connection interface, and supports high-

speed data rates up to 10.31Gbps. All TRENDnet 10G SFP+ ﬁber modules support connections for reliable, long- distance network

applications.

TEG-10GBS20

Fiber Applications

Long- distance ﬁber networking for

manufacturing, business parks,

and school campus applications.

Fiber Distance

Single mode 10G SFP+ transceiver

spans distances up to 20km (12.42

mi.) at 10G speeds.

Compatibility

Hot-pluggable SFP+ transceiver works

with an MSA compliant 10G SFP+ slot.

NETWORKING SOLUTION

TEG-10GBS20

FEATURES

Fiber Distance

Ideal for long-range networking

distances up to 20km (12.42 mi.)

Fiber Interface

This single mode ﬁber SFP+

transceiver supports LC-

type duplex connector

Fiber Wavelength

Single mode ﬁber SFP+ module

compatible with 1310nm

wavelength

Data Rate

10G SFP+ supports data rates

up to 10.31Gbps

TEG-10GBS20

Hot-Pluggable SFP

Hot-pluggable 10G SFP+

transceiver compatible with an MSA

compliant SFP slot

SPECIFICATIONS

Standards

• IEEE 802.3

• IEEE 802.3u

• IEEE 802.3z

• IEEE 802.3ae

• 10GBASE-LR

Device Interface

• SFP+ MSA Compliant

• LC duplex connector

Data Transfer Rate

• 10.31Gbps

Wavelength

• 1310nm

Optical Output Power

• -5 ~ 1 dBm

Distance

• 20km (12.4 mi)

Special Features

• Hot pluggable

• Metal enclosure

• DDM support

Sensitivity

• -15 dBm

Power

• Max. Consumption: 0.8W

Operating Temperature

• 0° – 70° C (32° – 158° F)

Operating Humidity

• Max. 95% non-condensing

Dimensions

• 58 x 13.4 x 12.6mm (2.2 x 0.5 x 0.5 in.)

Weight

• 18g (0.6 oz.)

Certiﬁcations

• CE

• FCC

Warranty

• Lifetime Warranty

Package Contents

• TEG-10GBS20

All references to speed are for comparison purposes only. Product speciﬁcations, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.

TRENDnet offers a lifetime warranty for all of its metal-enclosed network switches that have been purchased in the United States/Canada on or after 1/1/2015. Cooling fan and internal power supply carry a one-year

warranty.

20675 Manhattan Place • Torrance • CA 90501 • USA • T: 1-888-326-6061 • sales@trendnet.com • www.TRENDnet.com

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any

Updated: 7/18/2024
