Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

FIRST TIME USE

Wait at least two hours, after the installation, before connecting

the appliance to the power supply. Connect the appliance to the

power supply it starts the operation automatically. The ideal storage

temperatures for the food are preset in the factory.

After turning the appliance on, you must wait for 4-6 hours for the

correct storage temperature to be reached for a normally lled

appliance. Position the antibacterial anti-odour lter in the fan as

demonstrated in the lter packaging (if available). If the audible signal

sounds, it means that the temperature alarm has intervened: press the

button to switch o the acoustic alarms.

CONTROL PANEL

1. Refrigerator Temperature / Stand By

2. Temperature Indicator setting

3. Refrigerator Indicator

4. Alarm Indicator

5. Freezer Indicator

6. Freezer Temperature / Stop Alarm

1 2 63 54

SETTING THE TEMPERATURES

Press the Refrigerator Button to set a dierent temperature in the

refrigerator compartment.

Recommended setting for Refrigerator compartment is MED

Press the Freezer Button to set a dierent temperature in the freezer

compartment.

Recommended setting for Freezer compartment is MED

Led o Led on

LEAST COLD

MEDIUM

COOLEST TEMP

FAST FREEZING

ON/STAND-BY

Press the Refrigerator Temperature button for 3 seconds to

turn the appliance on stand-by.

When in Stand-by mode the light in the refrigerator compartment does

not turn on. Press the button again briey to reactivate the appliance.

To avoid an increase of food waste, refer to recommended setting and

Storage Time in User manual online.

FAST FREEZE

In order to preserve at best, please use the Fast Freeze function before

putting a large quantity of food in the freezer cavity.

Press the button (6) until all the three leds are on in order to set the

function.

The function turns o automatically after 26 hours, or manually by

selecting dierent freezer temperature.

Note: avoid a direct contact between the fresh food and the food that is

already frozen. To optimise the freezing speed, drawers can be removed

and the food can be placed directly on the bottom of the compartment.

* Available only on certain models

HOW TO STORE FRESH FOOD AND BEVERAGES

Legend

MINOR COOL ZONE

Suggested for the storage of tropical fruit, cans, drinks,

eggs, sauces, pickles, butter, jam

COOL ZONE

Suggested for the storage of cheese, milk, daily food,

delicatessen, yogurt

COOLEST ZONE/DRAWER

Suggested for storage of cold cuts, desserts, meat and

sh.

FRUIT & VEGETABLE DRAWER

FREEZER DRAWERS

FREEZING ZONE DRAWER

(Max cool zone)

Suggested to freeze fresh/cooked food

The load limits are determined by the particular construction (baskets,

containers, aps, drawers, shelves, etc.), or the load limits are determined by

natural load limits.

REFRIGERATOR COMPARTMENT

Multiow Air Distribution

The multiow helps to distribute evenly the cold air in the cavity for

a better food preservation. Foods can be placed on any shelf of the

appliance. Please pay attention to not obstruct the air distribution

vents thus ensuring its free movement.

Humidity control*

Open the humidity regulator (position B) if you want to store food in a

less humid environment like fruit, or close it (position A) to store food

in a more humid environment like vegetable.

A B

Multi Fresh Zone

3 temperature selection to optimally preserve: Meat/Fish; Dairy; Fruit/

Veggies, oering also extra storage space for your fresh greens.

Settings:

LOW = Meat and Fish

MID = Dairy Food (Cheese and Yogurt)

HIGH = Fruits and vegetables

For the correct functioning of the “Multi Fresh zone” drawer, it is

necessary that:

• the appliance is turned on

• one of the following special functions is not selected: Standby,

Cooling-O, Vacation (in this case, remove the food contained in it).

Light system (depending on model)

This product contains a light source of energy

eciency class G

This product contains 2/4 lateral light sources

of energy eciency class F and a top light

source of energy class G

This product contains a light source of energy

eciency class G

This product contains a top light source of

energy eciency class G

FREEZER COMPARTMENT

Total No Frost system

The Total No Frost system eectively prevents ice formation, avoiding

the hassle of manual defrosting both in freezer and fridge cavity.

Its ventilation system provides perfect circulation of cold air in both

cavities thus avoiding ice builds up.

Ice cubes*

Fill 2/3 of the ice tray with water and put it back in the freezer

compartment.

Do not use sharp or pointed objects to remove the ice under any

circumstances.

The quantity of fresh food that can be frozen in 12 and 24 hours is written

on the rating plate.

Easy access tray*

Freezer tray is useful to easily access frequently used products, freeze

or simply store leftovers or small items.*

Fast Freeze Pad (Alu PAD)*

The metallic panel help to freeze faster the food.

For an easy cleaning the metallic panel can be removed, lifting it up

from the left angle.

Fresh Pad*

The Fruit & vegetable drawer is equipped with the Hygiene grid.

Thanks to the special design of this component fruits&vegetable are

not in contact with the natural leakages (as drip loss and moisture

from vegetables) that drop below the Hygiene grid. The Hygiene grid

is treated with Microban SilverShield® technology that reduces the

harmful bacteria by up to 99.9% on the surface of the crisper grid, for

enhanced preservation of fruit and vegetables**. The hygiene grid can

be removed to be washed when dirty, simply raising it and pulling it

out. It can be simply washed by hand, with water only or with common

neutral detergents for dishes. It can be washed also in the dishwasher.

After cleaning, dry before putting it back into place.

GENERAL INFORMATION

The drawers, baskets and shelves should be kept in their current position

unless otherwise specied in this quick guide.

The light system inside the refrigerator compartment uses LED lights,

allowing for better lighting than with traditional light bulbs, as well as for

very low energy consumption.

DISPOSAL

Doors and lids of the refrigeration appliance should be removed before

disposal in the landll, to avoid children or animals getting trapped inside.

REMOVING THE DRAWERS

Pull the drawers outwards as far as they will go, lift them up and remove

them. To get more volume, the freezer compartment can be used without

the drawers.

Make sure that the door is closed properly after putting the food back on

the grilles/shelves.

* Available only on certain models

** Independently tested by IMSL (Industrial Microbiological Services Ltd,

UK) using ISO 22196

Specyfikacje produktu

Marka:	Whirlpool
Kategoria:	lodówka
Model:	WHR 18 TD
Kolor produktu:	Biały
Wbudowany wyświetlacz:	Nie
Położenie urządzenia:	Wbudowany
Częstotliwość wejściowa AC:	50 Hz
Napięcie wejściowe AC:	220-240 V
Wysokość produktu:	1770 mm
Szerokość produktu:	540 mm
Głębokość produktu:	545 mm
Waga produktu:	65000 g
Szerokość opakowania:	580 mm
Wysokość opakowania:	1840 mm
Głębokość opakowania:	608 mm
Okres gwarancji:	2 lat(a)
Szerokość przedziału instalacji:	560 mm
Głębokość przedziału instalacji:	550 mm
Minimalna wysokość przedziału instalacji:	1776 mm
Maksymalna wysokość przedziału instalacji:	1786 mm
Poziom hałasu:	32 dB
Klasa emisji hałasu:	B
Klasa wydajności energetycznej:	D
Zawias drzwiczek:	Lewy
Waga wraz z opakowaniem:	67000 g
Typ lamp:	LED
Roczne zużycie energii:	179 kWh
Dwustronne drzwi:	Tak
Pojemność netto:	250 l
Pojemność lodówki netto:	182 l
Tworzywo półek:	Szkło
Minimalna temperatura pracy:	10 °C
Maksymalna temperatura eksploatacji:	43 °C
Światło wewnątrz lodówki:	Tak
Automatyczne rozmrażanie (lodówka):	Tak
System Multi-Airflow (lodówka):	Tak
Liczba półek w lodówce:	5
Liczba pojemników na warzywa:	1
Przegródki na drzwiach lodówki:	5
Funkcja Super Cool:	Nie
Pozycja zamrażarki:	Umieszczony w części dolnej
Pojemność zamrażarki netto:	68 l
Czas przechowywania podczas awarii zasilania:	7 h
Automatyczne rozmrażanie (zamrażarka):	Tak
Ocena w gwiazdkach:	4*
Pojemność zamrażarki brutto:	7 kg/24h
Liczba półek w zamrażarce:	1
Funcja szybkiego zamrażania:	Tak
Komora Fresh zone:	Tak
Alarm awarii:	Tak
Alarm przy otwiertych drzwiach:	Tak
Regulowane półki:	Tak
Maszyna do lodu:	Nie
Tryb klimatu:	SN-T
No Frost (lodówka):	Tak
No Frost (zamrażarka):	Tak
Liczba kompresorów:	1
Liczba wyjmowalnych półek:	3
Funkcja urlopu:	Nie
Dozownik wody:	Nie
Wskazanie błędu:	Nie
System chłodzenia:	Dynamiczne (wspomagane wentylatorem)
Wentylacja:	Tak
Wpuszczany uchwyt(y):	Tak
Liczba drzwi:	2 drzw.
Komora antybakteryjna:	Nie
Komora środkowa:	Nie
Ilość szuflad zamrażarki:	2
Sterowanie elektroniczne:	Tak
