Strona 1/6
MODEL
283TPD
Dual Designer Emitter Twin Plug
Blink-IR™
INSTALLATION INSTRUCTIONS
DESCRIPTION
The 283TPD “Twin-Plug” Designer Emitter is based on Xantech’s standard
283D Designer Emitter with two 3.5mm Mono-Mini plugs each with ‘diode’
isolation. The twin plug feature allows a single emitter to be shared by two
IR sources. For instance, one mouse emitter can now be connected to both
an IR receiver and a Xantech Multi-Zone Controller without having to place
two emitters on the front of the IR controlled source component.
Internally, the 283TPD contains components that are designed to keep the
IR signal path directed towards the emitter only, allowing both control
systems to be completely isolated. The plugs are gold plated to increase
durability and connectivity.
x In some cases it may be difficult to find the location of the IR sensor
on the component. Consult the owner’s manual of the unit, or the
manufacturer, for the exact IR sensor window location.
x Double-sided adhesive tape is included. If you move the emitter to a
different component, use this tape to replace the current adhesive
layer for the best adhesion.
x The shell, though dark in appearance, is transparent to infrared light,
allowing commands from a handheld remote control to pass through
it. This permits direct control of the equipment from a handheld
remote as well as from the 283TPD.
BLACK (IR OPAQUE) EMITTER SHIELD
x An optional shield, available from Xantech as model 28DES, fits over
the emitter head and the sensor window of the controlled component.
It prevents unwanted external IR signals from passing through or
leaking past it.
x Use the 28DES when you want the equipment to respond only to the
283TPD, such as in zone controlled systems.
