Needle stops in the UP position. A space

and stitch will be formed when the foot

control is pressed (Blue LED is on).

Positioning

Button

Stitch

Formation

LED

Lights

Needle/Loading

Positions

Needle stops in the DOWN position

and the next stitch will be an actual

stitch (Green LED is on).

Needle stops in the DOWN position

and the next stitch will be a stitch

space (Orange LED is on).

Loading position

(press and hold the positioning button

for approximately 2 seconds, Yellow

LED is on).

1. Insert or remove the bobbin case

2. Replace latch wire

3. Replace needle

Bobbin winder is

engaged

(All LED lights are off)

Bobbin winding completed

(Blue LED flashes on and off)

Warning

LED Lights

Orange LED light flashes on and off

1. Safety System is activated:

Side cover is open

Presser foot is raised

Latch wire is engaged in the release position

Foot control is pressed and presser foot is down when power is turned "ON"

2. Needle is in the down position and the presser foot is in the raised position.

3. Motor overload. When this occurs machine has to be turned off then turned back on

before using.

1. The Baby Lock Sashiko stitching will not unravel,so it is not necessary to make

tacking stitch.

2. Always stitch with fabric under the presser foot when machine is threaded.

3. Do not stitch over previous stitching or stitch down the same row of stitching.

4. Avoid stitching over pins.

5. Before removing bobbin case, changing needle, or replacing latch wire, place needle

in up position, remove fabric, and cut thread.

Important Notice
