For fastest service, please visit our website at
www.comfortproducts.net/support
e -mail: customerse rv ic e@comfortproduct s.net
Keep your sales receipt as documentation of your ownership.
CUSTOMER SERVICE
BLACK MIDBACK LEATHER CHAIR
OPERATION MANUAL
MODEL 60-5607M
1
CONTENTS
EXTRA SPARE HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
PART DESCRIPTION STOCK# QTY..
A
Back Cushion 61-5607A
1
B
Seat Cushion 61-5607B
1
C
Armrest (left)
Armrest (right)
61-ARMOL
61-ARMOR
1
1
D
Seat Plate 61-PLATEB
1
E
Gas Lift (seat post) 61-POSTA
1
F
Star Base 61-BASE5607M
1
G
Caster 61-CASTA
5
H
Gas Lift Cover
61-COVER
1
PARTS LIST
PART DESCRIPTION QTY.
I
Screwcaps
8
J
Washer
4
K
M6 x 20mm Screw
4
L
M6 x 25mm Screw
8
M
Allen Wrench
1
HARDWARE KIT
STOCK# 61-SCRWSETB
REPLACEMENT PARTS
IF YOU ARE MISSING ANY OF THE PARTS ABOVE, OR IF YOU HAVE A DAMAGED PART, PLEASE VISIT
WWW.COMFORTPRODUCTS.NET/SUPPORT. SIMPLY COMPLETE THE INFORMATION, AND THE PART YOU
NEED. THE PART WILL NORMALLY SHIP WITHIN 48 HOURS.
2
STEP 4
Turn assembled chair frame upright. Position the center
hole in seat plate (D) over the gas lift (E). Then carefully
lower the chair onto the gas lift.
ASSEMBLY INSTRUCTION (60-5607M)
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED
STEP 2
Align seat plate (D) over pre-drilled holes under seat
cushion (B). (NOTE the position of seat plate handle to
seat cushion FRONT). Attach seat plate (D) to seat cushion
(B) using four screws (K) and four washers (J) as shown.
Tighten securely with allen wrench (M).
STEP 1
Insert casters (G) into holes of star base (F). Insert gas lift
(E) into center hole of star base (F). Place gas lift cover (H)
over gas lift (E) as shown.
STEP 3
First, attach the left and right armrests (C) to the seat
cushion (B), using the four screws (L) and the screwcaps (I)
as shown. Then attach the left and right armrests (C) to the
back cushion (A) using four screws (L) and the screwcaps
(I) as shown.
G
F
E
H
Seat front
Seat plate
handle
E
I
L
C
A
B
L
I
L
L
I
I
FRONT
B
D
K
J
