For fastest service, please visit our website at
www.comfortproducts.net/support
e -mail: customerse rv ic e@comfortproduct s.net
Keep your sales receipt as documentation of your ownership.
CUSTOMER SERVICE
COMMODORE II BIG & TALL LEATHER EXECUTIVE CHAIR
OPERATION MANUAL
MODEL 60-5800T
1
CONTENTS
EXTRA SPARE HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
PART DESCRIPTION STOCK# QTY..
A
Back Cushion 61-5800TA
1
B
Seat Cushion 61-5800TB
1
C
Armrest (left)
Armrest (right)
61-ARM5800TL
61-ARM5800TR
1
1
D
Seat Plate 61-PLATE5800T
1
E
Gas Lift (seat post) 61-POST5800T
1
F
Star Base 61-BASE5800T
1
G
Caster 61-CAST5800T
5
H
Gas Lift Cover 61-COVER
1
I
Base Cover 61-COVERBC
1
J
Head Rest 61-5800THR
1
PARTS LIST
PART DESCRIPTION QTY.
K
Screwcaps
4
L
M8 x 25mm Screw
4
M
M8 x 35mm Screw
4
N
M8 x 70mm Screw
4
O
Small Allen Wrench
1
P
Large Allen Wrench
1
HARDWARE KIT
STOCK# 61-SCRWST5800T
REPLACEMENT PARTS
IF YOU ARE MISSING ANY OF THE PARTS ABOVE, OR IF YOU HAVE A DAMAGED PART, PLEASE VISIT
WWW.COMFORTPRODUCTS.NET/SUPPORT. SIMPLY COMPLETE THE INFORMATION, AND THE PART YOU
NEED. THE PART WILL NORMALLY SHIP WITHIN 48 HOURS.
2
STEP 4
Attach the left armrest (C) to the seat cushion (B) and back
cushion (A), using the screws (N) and the screwcaps (K) as
shown. Repeat for right armrest (C). Then attach headrest
(J) to back cushion (A) as shown. Simply insert the 2 posts
of headrest into the plastic clips at the top of the back
cushion, and adjust to the desired height.
ASSEMBLY INSTRUCTION (60-5800T)
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED
STEP 2
Align seat plate (D) over pre-drilled holes under seat
cushion (B). (NOTE the position of seat plate handle to seat
cushion FRONT). Attach seat plate (D) to seat cushion (B)
using four screws (L) as shown. Tighten securely with allen
wrench.
STEP 1
Insert casters (G) into holes of star base (F). Snap the
2-piece base cover (I) over center of base as shown. Insert
gas lift (E) into center hole of star base (F). Place gas lift
cover (H) over gas lift (E) as shown.
STEP 3
Place the back cushion (A) on a flat, clean surface such as a
table. Position the seat cushion (B) as shown and align the
four holes in the back and seat cushion together. Connect
the seat cushion to the back cushion using four screws
(M) as shown. Do not fully tighten until after armrests are
attached (see step 4).
Seat front
Seat plate
handle
H
E
G
F
I
I
D
B
L
FRONT
A
B
D
M
J
D
C
B
A
N
K
C
