Strona 1/2
1
Model
GT-DB-02w / GT-DB-02b
In the box
• Transmitter (doorbell, inscribable), incl. mounting
plate, 2 wall plugs, 2 screws and double-sided ad-
hesive foam.
• Receiver (mains connection plug)
• Operating instructions incl. warranty
Explanation of symbols
This symbol/signal word indicates a
hazard with a moderate risk which,
if it is not avoided, can result in fatal or serious injury.
This signal symbol/word warns of
possible material damage.
This symbol gives you additional useful informa-
tion on the layout or operation of the product.
Class III: appliances in this class are operated
with safety extra-low voltage (SELV).
Class II: increased or double insulation be-
tween active and touchable parts. Mostly
without connection to the protective conductor.
IPX4 Protection against splashing water.
IP20:
Protected against penetration by solid objects
with a diameter >12.5 mm. No protection against water.
Transmitter: suitable for indoor and outdoor
use.
Receiver: only for use indoors
Alternating current
RCM (Regulatory Compliance Mark)
The product complies with the requirements
of the applicable Australian standards.
Application notes and warnings
Before starting up the product, please read
and follow the instructions, particularly
the safety and installation instructions.
Keep the instructions for reference later and pass
them on to any subsequent owner.
The Transmitter (doorbell) is suitable for indoor and
outdoor use.
The Receiver (mains connection plug) is only suita-
ble for indoor use.
The product is designed for private use.
Metal objects can have a negative effect on
the range between the Transmitter and Re-
ceiver. Do not position the Transmitter and Receiver
on or near metal objects.
Risk of suffocation! Children play-
ing with the packaging fi lm can
become entangled in it and choke.
This electrically operated product is not a toy. Do not let
children play with the product or the packaging fi lm.
Keep the product out of reach of children.
This product can be used by children from age 8 and
by persons with reduced physical, sensory, or men-
tal skills or lack of experience and/or knowledge, if
they are supervised or have been instructed in safe
use of the product and have understood the result-
ing dangers.
Cleaning and maintenance may not be carried out
by unsupervised children.
Risk of electric shock! Do not op-
erate the Receiver (mains connec-
tion plug) with wet hands.
Keep the Receiver away from contact with mois-
ture/water or any other liquid.
Checking the package contents
Risk of electric shock! Do not make
any technical changes to the
Transmitter and Receiver. Do not open the hous-
ing and do not insert any objects into the inside of
the housing
If parts are visibly damaged, stop using the prod-
uct to prevent hazards.
Remove all parts from the packaging and check that
the contents are complete and undamaged. Contact
the service address given on the guarantee card if
necessary.
Dispose of the packaging material in an environ-
mentally friendly way.
Starting up
Fire risk!
Do not cover the connected Receiver (mains con-
nection plug), e.g. with fabric, paper or plastic.
Risk of damage!
Only connect the Receiver (mains connection plug)
if the mains voltage of the power socket matches the
data on the nameplate.
Connect the Receiver only to an easily accessible
socket, so that you can disconnect it from the mains
quickly in the event of a fault.
Installation
Before you install the Transmitter in the planned
place, make sure that it functions properly. The
Transmitter and Receiver must be connected fi rst if
necessary (radio connection).
- Connect the Receiver to the planned power socket.
- Press the Bell button on the Transmitter:
No signal at the receiver? –> Keep Melody
button 1 pressed for approx. 3 seconds until
2 short sounds can be heard.
Press the Bell button 2 briefl y within 30 seconds.
- Position the Transmitter in the planned place and
press the Bell button to make sure that the Re-
ceiver receives the signal from the transmitter.
The distance may be too large, or the signal
is disrupted by metal objects. In this case,
you can remove the reception by moving the
Transmitter or Receiver.
1
2
Disconnecting the connection between the Re-
ceiver and Transmitter
If you want to disconnect the Transmitter (door-
bell) from the Receiver, press the Melody but-
ton 1 for approx. 10 seconds. After 2 short sounds can
be heard for the second time, the radio connection no
longer exists.
Attaching the Transmitter with the adhesive foam
With the help of the foam, the Transmitter
(doorbell) can be connected horizontally or
vertically to a smooth surface. It can then be removed
from the mounting plate, if necessary, by pushing in
the direction of the labelling fi eld.
Attaching the Transmitter with wall plugs and
screws
Risk of electric shock! Before install-
ing, make sure that there are no wa-
ter pipes or power cables in the area of the drillholes!
Risk of damage!
DIY skills and tools are required for the permanent in-
stallation. Contact an experienced fi tter if necessary.
-
Push the mounting plate in the direction of the Bell
button to remove it from the back of the Transmitter.
- Use a screwdriver, for example, to clear the screw
holes provided.
- Position the mounting plate in the planned place
and mark the drilling points.
- Use a 6 mm drill bit to drill holes 35 mm deep.
- Insert the wall plugs and screw on the mounting
plate.
Use the elongated screw retainer of the mount-
ing plate to align the plate horizontally or verti-
cally before tightening the screw if the drilled holes
are not exactly horizontal or vertical.
- Position the Transmitter on the mounting plate
and push it in the direction of the Bell button.
Kinetic wireless doorbell
GT-DB-02wGT-DB-02b
User Manual
MODEL:
GT-DB-02w, GT-DB-02b
831615
02/2024
