INSTRUCTIONS FOR USE
Tuner Box S3 DAB+
漏 Pro-Ject Audio Systems 路 Tuner Box S3 DAB+ 路 Revision 24.05. 20 27
2
Dear music lover,
thank you for purchasing a Pro-Ject Audio Systems /DAB-tuner and webradio. FM
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such
as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never
place any naked flame sources, such as lighted candles on or near the device. The product shall not be used
in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
Make all connections whilst the tuner is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked red,
the left channel black or white.
Connection to a preamplifier/integrated amplifier
Connect the fixed RCA output (lef
lef
lef
lefleft/
t/
t/
t/t/rig
rig
rig
rigright
ht
ht
htht) to any line level input on your preamplifier.
The RCA output level is always FIXED at full output. Only the headphone output can be volume
adjusted.
Connection to an external DAC/digital preamp/integrated amp with digital inputs
Connect the digital optical or coax output to a digital optical or coax input on your DAC .
FM/DAB Antenna input
Connect the included FM/DAB antenna cable to the FM Ant. 75 Ohm input.
WiFi Antenna input
Connect the included WiFi antenna.
漏 Pro-Ject Audio Systems 路 Tuner Box S3 DAB+ 路 Revision 24.05.20 27
3
Mains power connection
Connect the included power supply to the socket of the tuner connecting the power supply
Po
Po
Po
PoPower 9V
wer 9V
wer 9V
wer 9Vwer 9V bef
bef
bef
befbefore
ore
ore
ore ore
to the mains.
Front panel controls
To switch on from standby or to standby
The push button on the left-hand side will toggle the tuner between its fully operational status and standby. The
blue LED above the stand-by push button shows that the unit is switched on.
Headphone Output
Connect headphones to the 6,3mm headphone output.
Tune/Volume/Select
In main menu screen: turn left/right to scroll through the menu; push to go one menu-step forward/select
In now playing screen: change volume for headphone output; push to stop/start playback
In sub-menus: turn left/right to navigate through sub-menus; push to go one menu-step forward/select
Menu
Switch between menu screen and now playing screen.
Back/Forward
Back/Forward in main menu screen: scroll left and right
Forward in now playing screen: change now playing screen design
Back in now playing screen or sub-menus: go one menu-step back
Specyfikacje produktu
| Marka: | Pro-Ject |
| Kategoria: | system hi-fi |
| Model: | Tuner Box S3 DAB+ |
