Installation Manual
Manuale di installazione
Manual de instalación
Manuel d’installation
Installationsanleitung
Models, Modelli, Modelos, Modèles, Modelle
C0522R C0530R C0630R C0830R C1030R
Introduction
The design of this modular remote cuber is the
result of years of experience with remote ice
machine refrigeration systems. Standard features
of this product include front accessible on-off
switches, always-visible indicator lights, mechanical
assist ice harvest for extra efficiency, automatically
adjusting water purge and a control system that
optimizes system operation.
This installation and user manual is divided into
three sections: Installation, Use and Operation and
Maintenance.
The Installation section provides the trade person
with the information needed to properly install and
start up this ice system. The Use and Operation
section provides the user with the information
needed to use the machine. The Maintenance
section contains the instructions and schedules for
the sanitation and cleaning of the machine.
Note the Caution and Warning symbols when they
appear on the product or in this manual. They
indicate potential hazards.
Keep this manual for future reference.
June 2007
Page 1
C0522 through C1030
Remote Condenser Models - Installation Manual
Table of Contents
Installation: Product Specifications ............................... Page 2
Model Number Description ................................... Page 3
C0522 Cabinet Dimensions ................................... Page 4
C0530, C0630, C0830 and C1030 Cabinet Dimensions .................... Page 5
Product Description and Electrical Requirements ....................... Page 6
Water .............................................. Page 7
Panel Removal ......................................... Page 8
Remote Condenser Location .................................. Page 9
For The Installer: Remote Condenser ............................. Page 10
Precharged Line Routing .................................... Page 11
Coupling Instructions ...................................... Page 12
Plumbing Requirements .................................... Page 13
Electrical ............................................ Page 14
Final Check List: ........................................ Page 15
Initial Start Up .......................................... Page 16
Adjustments ........................................... Page 17
Use and Operation ....................................... Page 18
Control Switches ........................................ Page 19
Options and Other Information ................................. Page 20
Cleaning, Sanitation and Maintenance ............................. Page 21
Remote condenser ....................................... Page 23
What to do before calling for service .............................. Page 24
Installation: Product Specifications
Location Limitations
This ice system is made up of three parts, the ice
making machine, or head; the remote condenser;
and the interconnecting tubing. The ice making
machine must be installed indoors, in a controlled
environment. Space must be provided near the
machine for service access. The remote condenser
may be installed above or below the ice machine,
per the limits stated later in this manual. The
remote condenser may be installed outdoors within
the temperature limits listed below. The
interconnecting tubing must be installed per the
directions stated in this manual, and the amount of
tubing exposed to uncontrolled temperatures must
be minimized.
Space Limitations
Although the machine will function with no
clearance to the top and sides, some space must
be allowed for service access. Building the
machine in with no access will cause higher service
cost, in many cases this extra cost may not be
covered by warranty.
Environmental Limitations, ice machine:
Minimum Maximum
Air temperature 10
o
C. 38
o
C.
Water
temperature
4
o
C. 38
o
C.
Water Pressure 1 bar 5 bar
Environmental Limitations, remote condenser
Minimum Maximum
Air temperature -6
o
C. 49
o
C.
Power Supply
Minimum Maximum
230 volt model 207 volts 253 volts
Power Cord Reference Table
Rated Current of Model
Nominal
Cross-Sectional Area
(mm
2
) of Conductors
3,1 through 6 amperes ,75
6,1 through 10 amperes 1,0
10,1 through 16 amperes 1,5
16,1 through 25 amperes 2,5
Warranty Information
The warranty statement for this product is provided
separately from this manual. Refer to it for
applicable coverage. In general warranty covers
defects in material and workmanship. It does not
cover maintenance, corrections to installations, or
situations when the ice machine is operated in
circumstances that exceed the limitations printed
above.
Product Information
The machine is a specialized version of a modular
cuber. A modular cuber does not include any ice
storage, it is designed to be placed onto an ice
storage bin or ice dispenser. Many installations
only require the matching bin, but some will need
an adapter to be placed between the ice machine
and the bin or dispenser. Additionally, the machine
must be connected to the correct remote
condenser and use the correct pre-charged tubing.
The machine is supplied with a full refrigerant
charge, field charging is not required.
This product cannot be stacked. See the chart for
application information.
June 2007
Page 2
C0522 through C1030
Remote Condenser Models - Installation Manual
