Strona 1/2
CLK Mode(12H/24H)
Mounting Shoe
While the default Maintenance Alert digit
200 RIGHTkm/m is flashing, Press the button
to choose km/m. Press the 200/400/600/800
left button to confirm and enter into Clock mode. (when the
ODO the Maintenance Alert digit you set, the will
appear on the screen to alert the rider, press the RIGHT
button seconds to cancel it.)3
Remove the battery cover from the bottom of the computer by using
a flat blade screwdriver, install battery with the positive (+) pole
facing the battery cover and replace the cover. Should the LCD
show irregular figures, take out the battery and reinstall it.
Attach the sensor transmitter to either front fork using the supplied
cable ties. Fit the magnet to a spoke using the diagram above as a
guide. Position the sensor & magnet as shown above. Take care to
align the magnet to either arrow on the sensor with 3~5 mm gap in
between.
Attach the mounting shoe with the cable ties
to the handlebars as shown in the diagram.
Attach the computer to the mounting shoe by sliding the unit until it
snaps firmly into position. To remove, press down on the release
catch, and remove the computer.
To check for proper speed function and sensor alignment, spin the
front wheel with the computer in speed mode. Adjust the position of
sensor and magnet if there is on or weak signal.
Computer
Wheel Size Input
‘ ’ appears on the screed when the battery has been installed, 2060
with one figure flashing enter the wheel circumference using the
formula below.
In the example above you would enter . Press the 2198 RIGHT
button to advance the digits as needed and the button to LEFT
confirm and advance. (The circumference ranges 0mm~9999mm),
press the button to enter mode.LEFT KM/M
Setting(km/h)/(m/h)
Press the button to choose or .RIGHT km/h m/h
Press the button to enter mode.LEFT CLOCK
Setting Maintenance alert
In mode, press the button for seconds to set the ODO LEFT 2 ODO
value. The initial value is . when one figure flashes, press the 0000.0
RIGHT button to adjust it, and the LEFT button to confirm and start
to set the next figure. NOTE: Before re-installing the
battery, take a note of your mileage and then re-enter
the value once the battery is replaced.
In CLOCK Mode, press the LEFT button for seconds 3
to enter 12/24H selection. Press once more to swap
between 12/24 hours. Press the RIGHT button to enter
the Hour mode, when the figure indicating HOUR
starts to flash, press the LEFT button to adjust it. Continue to press
the RIGHT button to enter the Minute mode, when the figure indicating
MINUTE starts to flash, press the button to adjust. Press the LEFT
RIGHT button to confirm & press the RIGHT button again to switch to
ODO mode.
Setting the Last value of Odometer
Sensor Wiring
Computer Battery Installation
-SPD CURRENT SPEED
-ODO ODOMETER (0.001~99999km/m)
-DST TRIP DISTANCE
-MXS MAXIMUM SPEED
-AVS AVERAGE SPEED
-TM ELAPSED TIME
-CLK CLOCK (12H/24H)
-SCAN
- “-” “+” COMPARATOR
-SETTING SPEED SCALE ,(km/h m/h)
-SETTING TYRE CIRCUMFERENCE (0mm~9999mm)
-SETTING THE LAST VALUE OF ODOMETER /ODO
-MAINTENANCE ALERT
-FREEZE FRAME MEMORY
-BACK LIGHT
-AUTO ON OFF /
16 function cycle computer
Instruction Manual
FUNCTIONS
Speedometer Sensor
Route the sensor wire up the fork blade,
using the cable ties to secure it. Make
sure it does not hinder the movement
of the front wheel.
SD-581G
≤3mm
TYRE DIAMETER IN MM
× 3.14=CIRCUMFERENCE
EG: - Wheel 686mm diameter
Calculate 686×3.14=2154.04
Enter first 4 digits ‘2154’
NOOFF
