Strona 1/22
Installation Manual
Manuale di installazione
Manual de instalación
Manuel d’installation
Installationsanleitung
Models, Modelli, Modelos, Modèles, Modelle
C1448, C1848, C2148W
Introduction
The design of this modular cuber is the result of
years of experience and testing. Standard features
include front accessible indicator lights and on-off
switches that provide the user with fast access to
critical information and easy operational control.
When desired, optional controls can add features
like ultrasonic bin ice level sensing, seven day
programmable bin ice level setting, remote lock out
and more.
This installation and user manual is divided into
three main sections: Installation, which provides
the trade person with the information needed to set
up and install this product; Use and Operation,
which provides the user with the information to use
the product; and Maintenance, which provides the
user with the information needed keep it operating
efficiently.
Note any Caution or Warning symbols when they
appear on the product or in this manual. They
indicate potential hazards.
June 2007
Page 1
C1448, C1848, C2148W
Air and Water Cooled Installation Manual
Table of Contents
Installation: Product Specifications ....................................Page 2
Product Information ............................................Page 3
Water ...................................................Page 4
Panel Removal ..............................................Page 5
Uncrate and Set Up ...........................................Page 6
Plumbing Requirements .........................................Page 7
Electrical .................................................Page 8
Initial Start Up ..............................................Page 9
Adjustments ...............................................Page 10
Use and Operation ............................................Page 11
Water flush setting ............................................Page 12
Switches .................................................Page 13
Options and Other Information ......................................Page 14
Cleaning, Sanitation and Maintenance ..................................Page 15
What to do before calling for service ...................................Page 16
Installation: Product Specifications
Location Limitations: The product is designed to be
installed indoors, in a controlled environment. Air
cooled models discharge very warm air into the
room out the back. Space must be allowed at the
left side and back for air intake and discharge.
Water cooled models discharge warm water into
the building’s drain. Space needs to be provided on
both sides and above for service access.
Space Limitations
Note: Although the machine will function, ice
capacity of air cooled machines will be significantly
reduced with minimal clearance at the sides, back
and top. Some space is recommended for service
and maintenance purposes on all models.
6" of space at the sides and back are required for
adequate operation. To get the most capacity,
locate the machine away from heat producing
appliances and heating ducts. Provide several feet
of space to the left for maximum ice capacity.
Walls or other large machines near to the ice
machine might also cause a reduction in ice
capacity. One foot behind and two feet above will
be required to make rated capacity.
Airflow is in the front, in the left side, out the back
(as viewed from the front).
Environmental Limitations
Minimum Maximum
Air temperature 10
o
C. 38
o
C.
Water
temperature
4
o
C. 38
o
C.
Water pressure 1 bar 5 bar
Power supply – acceptable voltage ranges
Minimum Maximum
230 volt model 207 volts 253 volts
Power Cord Reference Table
Rated Current of Model
Nominal
Cross-Sectional
Area (mm
2
)of
Conductors
3,1 through 6 amperes
,75
6,1 through 10 amperes 1,0
10,1 through 16
amperes
1,5
16,1 through 25
amperes
2,5
Warranty Information
The warranty statement for this product is provided
separately from this manual. Refer to it for
applicable coverage. In general warranty covers
defects in material or workmanship. It does not
cover maintenance, corrections to installations, or
situations when the machine is operated in
circumstances that exceed the limitations printed
above.
June 2007
Page 2
C1448, C1848, C2148W
Air and Water Cooled Installation Manual
Airflow Direction
