Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Product Diagram (LTLOCK4D)

ComponentsFunction

1Security Cable

• Used to secure a Device to a secure stationary

object.

2Bumper Spacers

• Prevents the Lock from scratching the

connected Device.

3Locking Hook• Used to connect the Lock to a Lock Slot.

4Release Button• Used to release the Lock from the Lock Slot.

5Dials• Used to enter the Lock’s combination.

6Guide Line

• Used to enter a combination on the Dials.

• Align the combination digits with the Guide

Line.

7Reset Screw

• Used to set a new combination.

Note: Once the combination is changed, if you

lose the new combination you will not be able to

reset the combination.

4-Digit Combination Laptop Lock

1

Requirements

For the latest requirements, please visit www.startech.com/LTLOCK4D.

• Default Combination = 0-0-0-0

Setting a New Combination

1. Align the numbers on the Dial with the Guide Line using the default combination

0-0-0-0.

2. Insert a Flathead Screwdriver (sold separately) into the Reset Screw and push the

Reset Screw in toward the Lock.

3. With the Reset Screw pushed in, turn the Reset Screw clockwise 90 degrees.

4. Rotate each of the Dials to the desired number.

5. Insert the Flathead Screwdriver into the Reset Screw and turn the Reset Screw

counter-clockwise 90 degrees moving the Reset Screw, back to its original position.

The Reset Screw will pop back out once it is in the original position.

Note: Be sure to write down the new combination and keep it in a secure location

away from the lock.

6. To set a new combination follow steps 1 - 5 using the new combination set up in

Step 4 instead of the default combination.

Locking a Device

1. Wrap the Security Cable around a secure stationary object and pull the Lock

through the loop on the Security Cable.

Security Cable

2. Press and hold the Release Button and insert the Locking Hooks into the Lock Slot

on a Laptop, Docking Station, or any other compatible Device.

2

3

4

5

6

7
