Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: December 30, 2019 4:34 PM

Product Diagram (LTULOCK4D)

ComponentsFunction

1Security Cable

• Used to secure a Device to a secure stationary

object.

2Bumper Spacers

• Prevents the Lock from scratching the

connected Device.

3Locking Hook• Used to connect the Lock to a Lock Slot.

4Adapter

• Used to change the Lock head to

accommodate dierent lock slots.

• Standard Slot = 3x7 mm slot

• Wedge Slot = 3.2x4.5 mm slot

• Nano Slot = 2.5x6 mm slot

5Adapter Slot• Used to house the Adapter.

6Guide Line

• Used to enter a combination on the Dials.

• Align the combination digits with the Guide

Line.

Universal 4-Digit Combination Laptop Lock | Pivot and Rotate Hinge

7

Release Button

• Used to release the Lock from the Lock Slot.

8Dials• Used to enter the Lock’s combination.

9Reset Screw

• Used to set a new combination.

Note: Once the combination is changed, if you

lose the new combination you will not be able to

reset the combination.

Requirements

For the latest requirements, please visit www.startech.com/LTULOCK4D.

• Default Combination = 0-0-0-0

Setting a New Combination

1. Align the numbers on the Dial with the Guide Line using the default combination

0-0-0-0.

2. Insert a Flathead Screwdriver (sold separately) into the Reset Screw and push the

Reset Screw in toward the Lock.

3. With the Reset Screw pushed in, turn the Reset Screw clockwise 90 degrees.

4. Rotate each of the Dials to the desired number.

5. Insert the Flathead Screwdriver into the Reset Screw and turn the Reset Screw

counter-clockwise 90 degrees, moving the Reset Screw back to its original position.

The Reset Screw will pop back out when it is in the original position.

Note: Be sure to write down the new combination and keep it in a secure location

away from the lock.

6. To set a new combination follow steps 1 - 5 using the new combination set up in

Step 4 instead of the default combination.

Installing a Lock Adapter

1. Select the Adapter that ts the Lock Slot on the Device you are trying to secure.

2. While pressing the Release button, insert the Adapter into the Adapter Slot on the

Lock, making sure that the Lock Adapter is pushed all the way into the Adapter

Slot and ush with the Lock.

34

5

1

2

7

8

6

9
