FMB150
FMB150 is an ADVANCED GSM/GNSS/BLUETOOTH®LE tracker with integrated CAN data processor. It is compact 2
in 1 solution: GPS tracker and CAN adapter inside! Device allows to read CAN data from a wide range of various
vehicles, including light & electric vehicles, trucks and buses. With the current software version FMB150 can be used
in advanced applications as logistics, delivery services, utility transport, car sharing and more. For now, one SW option
is available to full your business demands:
A default FMB150 software version with LV-CAN parameters, including fuel level, consumption, odometer, CAN speed,
pedal position.
Supported vehicle types: light vehicles, electric vehicles, trucks and buses.
GNSS/GSM TRACKER WITH INTEGRATED CAN ADAPTER AND INTERNAL
GNSS/GSM ANTENNAS AND INTERNAL BATTERY
NEGATIVE INPUT
Allows easier installation of
accessories
INTEGRATED CAN DATA PROCESSOR
Allows to monitor real fuel
consumption and level, full mileage,
engine temperature and more
2G NETWORK
Quad band cellular connectivity
with global coverage
CAN DATA FOR EV VEHICLES
CAN module allows data reading
from electric vehicles (EV)
ELECTRIC
VEHICLES
LIGHT
VEHICLES BUSESTRUCKS
Product page
DATASHEET // FMB150
Module
Name Teltonika TM2500
Technology GSM/GPRS/GNSS/BLUETOOTH® LE
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS
Receiver Tracking: 33
Tracking sensitivity -165 dBM
Position accuracy < 2.5 CEP
Velocity accuracy < 0.1m/s (within +/- 15% error)
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
Cellular
Technology GSM
2G bands Quad-band 850 / 900 / 1800 / 1900 MHz
Data transfer GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B
Data support SMS (text/data)
Power
Input voltage range 10 - 30 V DC with overvoltage protection
Back-up battery 170 mAh Li-Ion battery 3.7 V (0.63 Wh)
Power consumption
At 12V < 6mA (Ultra Deep Sleep)
At 12V < 8mA (Deep Sleep)
At 12V < 11mA (Online Deep Sleep)
At 12V < 20mA (GPS Sleep)
At 12V < 35 mA (Nominal with no load)
At 12V < 1.5 A Max. (with full Load / Peak)
BLUETOOTH® technology
Specication 4.0 + LE
Supported peripherals Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support
Physical specication
Dimensions 65 x 56.6 x 20.6 mm (L x W x H)
Weight 55 g
DATASHEET // FMB150
Copyright © 2024, Teltonika. Specications and information given in this document are subject to change by Teltonika without prior notice.
* in progress
Interface
Digital Inputs 3
Negative Inputs 1 (Digital Input 2)
Impulse Inputs 2 (Digital Input 1, Digital Input 2)
Digital Outputs 2
Analog Inputs 2
CAN interfaces 2
1-Wire 1 (1-Wire data)
GNSS antenna Internal High Gain
GSM antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 3 status LED lights
SIM Micro-SIM or eSIM
Memory 128MB internal ash memory
Operating environment
Operating temperature (without battery) -40 °C to +85 °C
Storage temperature (without battery) -40 °C to +85 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP41
Battery charge temperature -0 °C to +45 °C
Battery discharge temperature -20 °C to +60 °C
Battery storage temperature -20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
Features
CAN Data Fuel Level (Dashboard), Total fuel consumption, Vehicle speed (wheel), Vehicle driven distance, Engine speed (RPM),
Accelerator pedal position
Sensors Accelerometer
Scenarios
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling
detection, Immobilizer, iButton Read Notication, Unplug detection, Towing detection, Crash detection, Auto Geofence,
Manual Geofence, Trip
Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Conguration and rmware update FOTA Web, FOTA, Teltonika Congurator (USB, Bluetooth), FMBT mobile application (Conguration)
SMS Conguration, Events, DOUT control, Debug
GPRS commands Conguration, DOUT control, Debug
Time Synchronization GPS, NITZ, NTP
Ignition detection Digital Input 1, Accelerometer, External Power Voltage, Engine RPM
Certication & Approvals *
Regulatory CE-RED, E-mark, Reach, RoHS, Anatel
