DS-PDPC12P-EG2

WiredPIR-CameraDetector

UserManual

EN50131-2-2:2017

EN50131-1+A1+A2+A3

SecurityGrade2

EnvironmentClassII

HangzhouHikvisionDigitalTechnologyCO.,Ltd.No.555QianmoRoad,BinjiangDistrict,Hangzhou310052,China

UD28855B

1

356

4

1

2

3

4

6

5

English

Appearance

1.SupplementLight2.Camera3.LED

4.DIPSwitch5.TamperButton6.WiringTerminals

Installation

A.Mountingwithgum.

B.Mountingwithscrews.

Wiring

1.Poweredbythecontrolpanel.

2.Poweredbytheadapter.

DetectionRange

AddressSettings

ConfiguretheaddressviaDIPswitchofthedetectorbefore

poweringonthesystem.Theaddressshouldbeintherange

(0to63).Theaddressofeachdetectorshouldbeunique.

Thebinaryvalueshowninthediagramis000011,which

meansthedecimalvalueis3,sotheaddressofthedetector

is3.

PoweringOn

Iftheindicatorflashesblueallthetime,itmeansthePIR

sensorisnotready.

Specification

Pleaseusethepowersuppliescomplywiththerequirementsof

EN50131-6attheappropriategradeandenvironmentalclass.

DetectionRange

DetectionAngle

Sensitivity

PetImmunity

FieldAngle

ImageType

Resolusion

FillLight

Day/NightSwitch

LEDIndicator

TransmissionTechnology

TransmissionRange

PowerConsumption

PowerSupply

TypicalVoltage

OperationTemperature

StorageTemperature

OperationHumidity

Dimension(WxHxD)

Weight

MountingHeight

12m

85.9°

Auto,High,Pet

30Kg

109°(H),60°(V)

JPEG

1920x1080,1280x720,640x480

InfraredLight

Color/Black&White

Blue(Alarm),Orange(Fault)

Speed-XBus

1Km

100mAMax

9to16VDC

12VDC

-10°Cto55°C(14°Fto131°F)

-20°Cto60°C(-4°Fto140°F)

10%to90%

73mmx130.5mmx56.7mm

195g

1.8to2.4m

56.7mm

12

12

10m1m2m4m6m8m

10m1m

2.4m

2m4m6m8m

10m

12m

1m

2m

4m

6m

8m

12m

12m

85.9°

DetectionRange

52zones

4planes

ThisPIRdetectorisapprovedat1.8

m~2.4mmounted.

Recommendedmountingheight:2.2m.

Pleasedonotobscurethedetector’s

fieldofviewpartiallyorcompletely.

LowbitHighbit

BIN=000011

=1=0

00

11

Address=3

BINAddressBINAddress

0000011

0000000

11100056

11011155

0000102

11100157

0000113

11101058

0001004

11101159

0001015

11110060

0001106

11110161

0001117

...

11111062

11111163

73mm

130.5mm

1

4

5

6

2

3

NOTREADYREADY

PoweringOn

7times1time

Enrollment

Succeeded

D-D-

D-D-

Detector

Detector

Adapter

ControlPanel

ControlPanel

D+D+

D+D+

-+

-+

-+

COMAUX

2

3

A

<30Kg

3

B

4

PA_3.5×25
