ifi-audio.com

accessory

Ver1.0

Technologies:

•Galvanic Isolation of theSPDIF signal

• REclock® and REgenerate®

• 10MHz Global Master Timing® clocklow-jitter

• Gold-plated copper EMI/RFI shielding

• Tantalum capacitors

• USB Type-C power socket

• "Quieter than battery" super-silent iPower 5V included

Specifications:

Supported Signals: 192/176.4/96/88.2/48/44.1kHz;

16 to 24 Bit, MQA, DSD/DoP,

Dolby Digital, DTS

Input: Combo optical mini-jack &

gold-plated coaxial connector

(impedance 75)Ω

Outputs: Gold-plated coaxial connector

(impedance 75) & Ω

optical mini-jack

Power Supply: Type-C USB, 5V/500mA

(iPower 5V included)

Dimensions: 76 x 19 x 20 mm

3.0" x 0.7" x 0.8"

Weight: 56 g 1.98 oz)(

Warranty period: 12 months

*Specifications are subject to change without notice.

1. SPDIF Output (coaxial)

Connect to the DAC or amplifier’s coaxial digital input.

2. SPDIF Output (optical)

Connect to the DAC or amplifier’s optical digital input.

3. SPDIF Input (coaxial/optical)

Connect the digital output from the host (Apple TV,

Google Chromecast, PS4, Xbox, CD transport etc).

4. LED

5. DC 5V Power

Please connect SPDIF iPurifier2 to the enclosed power

supply, the super-silent iPower. SPDIF iPurifier2 must

ONLY be powered by 5 volts.

Tip: For best performance upgrade iPower to an ultra-low noise iPower X 5V power

supply.

LED

Red

Blue

Magenta

Cyan

White

Mode

Unlock

44.1/48kHz

88.2/96kHz

176.4kHz

192kHz

SPDIF iPurifier2

4

2

1

3

5
