Strona 1/4
Inator for SUP
(Stand Up Paddle-Boards & Water Sport Pool Inatables)
SLPUMP10
Electric Air Pump Compressor
www.SereneLifeHome.com www.SereneLifeHome.com
CATALOGUE
Inflation inlet
Pressure value LCD screen
Pressure unit toggle button
+ Button increases PSI output
- Button lowers PSI output
On/off button
DC plug
Air tap
Hose
Flexible conduit adaptor
Air inlet
1
2
3
4
5
6
7
8
9
10
11
2
3
4
5
6
1
10 11
7
8
9
16.00
I. Product Introduction.......................................1
II. List of Accessories........................................1
III. Details of Accessories..................................1
IV. Safety Instructions........................................ 2
V. Inflation Operation...................................... 3-4
VI. Precautions.................................................. 4
VII. Fault Handling............................................. 5
VIII. Maintenance and Storage.......................... 5
IX. Suggestions................................................. 5
1
Please read instruction to ensure that you understand your
product operation and are able to safely and eectively use this product.
I. PRODUCT INTRODUCTION
SLPUMP10 is an intelligent DC electric pump with the preset
pressure LCD screen, which can be used for inatable tent, SUP,
etc. Thanks to the intelligent pressure system, for example, if a
pressure value is preset, when the pressure reaches the preset
pressure value, the pump will automatically stop inating.
II. LIST OF ACCESSORIES
Please make sure that the following accessories are in the
box before using it, if any missing, please contact with the
local supplier.
III. DETAILS OF ACCESSORIES
Air pump Hose Instruction Book
www.SereneLifeHome.com www.SereneLifeHome.com
V. INFLATION OPERATION
• Connect the end with Flexible conduit adaptor of the hose
with the air pump ination inlet (1), and twist clockwise to
tighten, as Figure 1.
• Install the other end of the hose into the supporting air tap of
the air bag (step 2 in Figure 2), and twist clockwise to tighten
it, and then insert the ination valve of the air bag and twist
clockwise to x it (step 2 in Figure 2).
• Plug the DC plug into 12V DC socket.
• Press the pressure unit toggle button to select the unit
you need.
• Press or to set the pressure value you need, with the
pressure range value from 0 to 16PSI, (1PSI=0.0689BAR)
• After nishing the above steps, press the power switch button
to start to inate.
• During the inating process, you can press the PSI pressure
output button or button to increase or reduce the
pressure value, press the pressure unit toggle button to
switch the unit, and press the On/O button to stop.
32
IV. SAFETY INSTRUCTIONS
• Warning: In order to reduce the risk of injury, keep out of reach
of children. Always supervise children and incapacitated
person contacting or using this air pump.
• Warning: Keep the packaging materials away from children
• Warning: This product is not applicable for persons with
declining physical strength, sensory ability or mental capacity,
and person lack of skill unless they are under the protection of
their guardians, supervised and directed at the same time.
• Warning: Before moving, maintaining, repairing or adjusting
this product, pull out the DC plug from the socket.
• Warning: Please do not bury the wire in soil, and place in a
safe environment where it won't be damaged by mower or
other equipment.
• Warning: If power wire is damaged, the power wire must be
changed by the manufacturer or its service agent or similar
authorized personnel, in case of any risk.
• Warning: DON'T PLUG OR PULL THE DC PLUG if you are
standing in a place with water or your hands are wet.
• Warning: Before inating, please pay attention to check the
maximum bearable pressure of the inatable product because
the air bag may be damaged upon exceeding the maximum
bearable pressure.
• Warning: The purpose of using this product is limited to the
description in the instruction book.
• Warning: Before using, please check the cigarette lighter
socket to make sure that there is no rust or residue inside. The
cigarette lighter socket with poor electric conduction may
cause overheating of the product or power source, which will
damage the product. （Figure 1） （Figure 2）
