PoE Injector

Overview

Features

• Complies with IEEE802.3af standard

• Cost saving, no power cabling for Ethernet network

device

• Delivers power and data over the single cable up to

100 meters

• Advanced Auto-Sensing Algorithm enables providing

power with 802.3af PD

• Supports power classication, Auto-determine the

necessary power requirements

• High safety with Short Circuit Protection

• Plug & Play installation, requires no conguration

• External 48VDC power supply

The PoE Injector POE150S (TL-POE150S) fully complies with IEEE 802.3af standard, and can work with

all IEEE 802.3af PoE compliant PDs (Powered Devices) or PoE Receiver Adapters, such as TP-LINK’s

POE10R, or other equivalent product, to expand your network to where there are no power line or

outlet, where you wish to x device such as AP, IP Camera or IP Phone, etc.

Diagram

Specications

www.tp-link.com

Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or

Product Picture

Model POE150S

Standards IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af

Ports

1 10/100/1000Mbps Auto-Negotiation RJ45 LAN port(LAN IN)

1 10/100/1000Mbps Auto-Negotiation RJ45 PoE port(POWER+DATA OUT)

1 power socket(DC IN)

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100 SE-TX: UTP category 5, 5e cable (maximum 100m)BA

EIA/TIA-568 100Ω STP (maximum 100m)
