Protocol manuals for developers: available for download at

https://github.com/velbus

Features

• motion detector for indoor use (wall or ceiling)

• housing included for surface mounting

• two output channels for motion detection with adjustable timeout

• two output channels for light dependent motion detection with adjustable light

sensitivity and timeout

• output channel for absence detection with adjustable timeout

• two output channels for twilight detection (dark and light) with adjustable light

sensitivity, reaction time and timeout

• supports extensive day, week and year programs with built-in astronomical

clock for locking/unlocking the output channels

• configuration through Velbus PC interface (VMB1USB, VMBRSUSB) and the free

VELBUSLINK software

• electronically addressable (up to 250 addresses)

Specifications

detection angle100°

detection distancemax. diameter 6 m (at 2.5 m height)

light sensitivity1 - 100 lux

required voltage supply15±3VDC

current consumption10 mA

dimensionspart to be built in: 55 x 15 x 15 mm

(fits through an Ø 18 mm hole)

PIR sensor: Ø 22 mm (mounting depth 20 mm)

housing for surface mounting:

Ø 75 mm / height 35 mm

mounting hole: without mounting accessory

Ø 18mm; with mounting accessory Ø 20-22mm

VMBPIRMdatasheet

Mini motion and twilight sensor for

recessed or surface mounting

The VMBPIRM is much more than a miniature motion

detector for indoor use. You can simultaneously use

motion, twilight and even absence detection. The built-

in astronomical clock allows the VMBPIRM to operate

time-dependently. The module also detects motion for

a passage signal and light dependent motion for lighting

control. Thanks to its housing (included), the VMBPIRM is

also suited for surface mounting.

VELBUS VMBPIRM•

Legen Heirweg 33 9890 Gavere Belgium••

velbus.eu

1
