08905087A - 1 -

INSTALLATION INSTRUCTIONS

XSS26100W

100Watt, Speaker Selector Volume Control

A/B Source Selection

6 Stereo Speaker Channels

DESCRIPTION

The XSS26100W provides an easy-to-use, easy-to-install, centralized speaker control unit. Premium

components are used to provide high-quality acoustical speaker distribution and independent volume

control. The XSS26100W requires no external power source.

SPECIFICATIONS

Source input selectable, A or B switches.

Dimensions: 17.5” W x 2.5” H x 6.25” L (with feet installed)

Frequency response: 20Hz to 20kHz ± 1dB

Attenuation: 11 steps plus OFF.

 Adjustable impedance matching. 4- or 8-Ohm speaker compatible.

Recessed area allows the use of custom labels or fine permanent markings.

Removable screw terminal connectors used with 12 to 22 AWG wiring.

Rack-mount ears and hardware included.

12 STEP VOLUME CONTROL

INDIVIDUAL ROOM ON/OFF SOURCE SWICH

INDIVIDUAL ROOM A/B SOURCE SWITCH

RECESSED AREA FOR CUSTOM ROOM

LABELS

XSS26100W

SPEAKER

SELECTOR 2X6

IMPEDANCE PAIR SELECTOR

REMOVABLE CONNECTORS

TO AMPLIFIER
